Водонепроницаемый сварочный аппарат
- Категория: Другие дуговые сварочные аппараты >>>
- Поставщик: Dongguan,Jone,Welding,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.28 $* | 0.21 $* |
| Aug-16-2025 | 0.50 $* | 0.49 $* |
| Jul-16-2025 | 0.99 $* | 0.63 $* |
| Jun-16-2025 | 0.76 $* | 0.28 $* |
| May-16-2025 | 0.53 $* | 0.79 $* |
| Apr-16-2025 | 0.21 $* | 0.39 $* |
| Mar-16-2025 | 0.53 $* | 0.77 $* |
| Feb-16-2025 | 0.60 $* | 0.69 $* |
| Jan-16-2025 | 0.60 $* | 0.31 $* |
Характеристики
Model | MMA-200B | MMA-250B | MMA-300B |
Type | IGBT 1PCB | IGBT 1PCB | IGBT 1PCB |
AC Input Voltage(V) | 220V (110V/220V can do) | 220V (110V/220V can do) | 220V (110V/220V can do) |
Rated Input Power Capacity(KVA) | 5 | 6.2 | 7 |
Input Frequency(Hz) | 50/60 | 50/60 | 50/60 |
Non-load Voltage(V) | 56 | 56 | 56 |
Output current range(A) | 20-200 | 20-250 | 20-300 |
Rated Duty Cycle(%) | 60% | 60% | 60% |
Efficiency(%) | 85% | 85% | 85% |
Class of Insulation | F | F | F |
Protection class of case | IP21 | IP21 | IP21 |
Electrode diameter (mm) | 1.6-3.2 | 1.6-3.2 | 1.6-4.0 |
Quick joint Size(mm) | 35-50 | 35-50 | 35-50 |
Input power cable(m) | 1.8 | 1.8 | 1.8 |
N.W./G.W.(kg) | 3.8/5.6 | 4/5.8 | 4.2/6 |
Machine Size(LxWxH mm) | 310*137*225 | 310*137*225 | 310*137*225 |
Package(LxWxH mm) | 350*206*275 kraft paper box | 350*206*275 kraft paper box | 350*206*275 kraft paper box |
Accessories | 1.8m 16mm² 200A holder | 1.8m 16mm² 200A holder | 1.8m 16mm² 200A holder |
1.2m 16mm² 300A clamp | 1.2m 16mm² 300A clamp | 1.2m 16mm² 300A clamp | |
mask,brush,belt,manual | mask,brush,belt,manual | mask,brush,belt,manual |
