Индивидуальный заказ oem odm монослойная Светодиодная лента печатная плата
- Категория: ПП и сборные ПП >>>
- Поставщик: Shenzhen,Dreamland,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.23 $* | 0.69 $* |
| Aug-18-2025 | 0.71 $* | 0.33 $* |
| Jul-18-2025 | 0.88 $* | 0.68 $* |
| Jun-18-2025 | 0.90 $* | 0.27 $* |
| May-18-2025 | 0.61 $* | 0.22 $* |
| Apr-18-2025 | 0.94 $* | 0.74 $* |
| Mar-18-2025 | 0.76 $* | 0.77 $* |
| Feb-18-2025 | 0.59 $* | 0.87 $* |
| Jan-18-2025 | 0.36 $* | 0.45 $* |
Характеристики
Product Description
We produce 1-10 layers flexible PCBs,and 2-12 layers flex-rigid PCBs.
For flexible PCBs, we're professional at multi-layer FPC, FPC cable, keyboard FPC, impedance control flex pcb, 0.05mm extra thinner FPC, LED FPC, transparent flexible pcb,etc.
Item | Specification |
FPC for led lighting | Support from design to mass production |
Sheet size | 250*500mm, 300*600mm, 250*1200mm, etc |
Test | 100% |
Size Information
Item | FPC Capability |
Product types | Single layer, double layer,multi-layer, hollow FPC, separated-layer FPC, flex-rigid |
Layer | 1-14 layer flex pcb, 2-14 layer flex-rigid pcb |
Maximum finished board size | 250*5000mm |
Board thickness | FPC,0.06-0.4mm; Flex-rigid PCB, 0.25-6.0mm |
Min. trace width & spacing | 0.045/0.045MM |
Base material | PI, PET, Electrolytic Copper, Rolled Copper |
Tolerance for finished product | ±0.03mm |
Copper thickness | 12UM, 18UM, 36UM, 70UM |
PTH Hole Dia.Tolerance(plated-through-hole) | ±0.05mm |
Stiffener | FR4/PI/PET/SUS/PSA |
Impedance Control of Finished Product | 50Ω - 120Ω |
Acceptance criteria | Factory production standard, GB；IPC-650, IPC-6012, IPC-6013 II, IPC-6013 III, etc |
Related Products
Company Introduction
Shenzhen Dreamland Electronics Co., Ltd. is the group company, one of the dynamic high-tech PCB circuit suppliers, and provides
one-stop PCB solution service in China. We rapidly expand in terms of capacity and technology in recent years, especially in the
areas of Flexible PCB, Flex-rigid PCB, etc.
one-stop PCB solution service in China. We rapidly expand in terms of capacity and technology in recent years, especially in the
areas of Flexible PCB, Flex-rigid PCB, etc.
Our Services & Strength
1, NO MOQ
2, 24 hours fast circuit board accepted
3, 90% engineers with 10 years experience in Flexible PCB industry
4, We develop our time to Quality controls and quality assurance
5, OEM & ODM solution
6, Turkey solution for PCB assembly, SMD, DIP.
Packing&Shipping
The PCB boards will be vacuum packed，and put PE film buffer in the carton.
Small batch will choose the DHL,UPS,FedEx,etc.
Medium and large quantities will be delivery by air, or by sea.
