A. Integrated internal HVIL B. Two-stage, tool or thumb activated latching C. No tool required to unmate D. Sealing, IP67 (mated), IP6K9K E. Touch-proof F. Multiple coding positions G. CPA available
Main Application of HVIL Connectors:
Specially designed for DC-DC, air-conditioner, battery, inverters, junction boxes, power distribution boxes and other equipment in xEV device applications.
Specifications
Rated Voltage
960V AC/DC
Rated Current
150A MAX
Withstand Voltage
3000V AC
Insulation Resistance
≥500MΩ
Cable Range
16-35m㎡
Connection Type
Terminal machine
Mating Cycles
>100
Shielding
360°
IP Degree
IP67 IP6K9K(Mated)
Operating Temperature
-40℃~125℃
Salt Spray
MAX 96h
Flammability Rating
UL94 V-0
HVIL
Intergrated Inside
Positions
1pin/ 2pin/ 3pin
Shell
PA66/ Zinc alloy
Contact
Cooper alloy,Silver plating
Sealing
Rubber
How to order
HVIL Products Overview
Renhotec All HVIL Connectors
Products Series
Rated Current
Position
Shell materials
Orientation
HVIL23
23A Max
2
PA66
Straight
3
PA66
Straight
HVIL35
35A Max
2
Zinc Alloy
Straight
3
Zinc Alloy
Straight
HVIL50
50A Max
2
PA66
Straight
HVIL125
125A Max
1
Zinc Alloy
Straight
2
PA66
Straight/ Right Angle
HVIL150
150A Max
2
PA66
Straight
HVIL200
200A Max
1
Zinc Alloy
Straight/ Right Angle
2
PA66
Straight/ Right Angle
HVIL250
250A Max
1
Zinc Alloy
Straight/ Right Angle
HVIL400
400A Max
1
Zinc Alloy
Straight/ Right Angle
HVIL500
500A Max
1
Zinc Alloy
Straight/ Right Angle
