Печатная плата 94v0 PCB с индивидуальным дизайном от

Описание и отзывы

Трекер стоимости

Характеристики









 Cooperation mode:

1. Schematicdesign: circuit schematic can be designed according to customer’s requirements.



2, PCB design: PCB diagram can be designed according to the schematic from customer. PCB and bill of materials can be analyzed on the basis of customer’s samples.



3, Software design: SCM software development and design, can be written according to customer’s requirements, with the needed function. Or rewrite some part of software to fit customer's actual hardware.









PCB Board Fabrication Capabilities:



Layer	1,2,4 or 6,upto 18 layers
Material	FR4,CEM1,CEM3,Hight TG,FR4 Halogen Free,FR1,FR2
Order Quantity	1-500,000
Board shape	Rectangular,round,slots,cutouts,complex,irregular
Board type	Rigid,flexible,rigid-flexible
Board material	FR-4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc
Board cutting	Shear,V-score,tab-routed
Board thickness	0.2~4.0mm,Flex 0.01~0.25''
Copper weight	1.0,1.5,2.0oz
Solder mask	Double-sided green LPI,Also support red,white,yellow,blue,black
Silk screen	Double-sided or single-sided in white,yellow,black,or negative
Silk screen min line width	0.006'' or 0.15mm
Max board dimensions	20inch*20inch or 500mm*500mm
Min drill hole diameter	0.01'',0.25mm.or 10 mils
Surface finish	HASL,Nickle,Imm Gold,Imm Tin,Imm Silver,OSP etc
Board thickness tolerance	± 10%
Copper weight tolerance	± 0.25oz
Minimal slot width	0.12'',3.0mm,or 120mils
V-score depth	20-25% of board thickness
Plated through holes	Yes
Sink holes	Yes
Design file format	Gerber RS-274X,274D,Eagle and AutoCAD'S DXF,DWG

 Mode of production cooperation:

1. The written program, schematic, PCB data and bill of materials can be sent to customer for the processing of program  and circuit boards.



2, We can design the program for customer, help to produce circuit boards according to customer’s requirements. Multi-style cooperation to meet different customer’s needs.



3, Development and design, low charge. only cost and development fees are required, which can be returned after a certain amount of orders. Can be developed and designed on basis of customer's program requirements.





Designable PCB board:

Intelligent circuit boards for domestic appliance, like electric water heaters, rapid thermal water heaters, solar water heaters, air conditioners, refrigerators, microwave ovens, dishwashers, disinfection cabinets, water dispensers, washing machines, vacuum cleaners, rice cookers, cold fans, water purifiers, etc.
