Хорошая цена медицинское высокочастотное мобильное рентгеновское

II Standard Configuration

1 ,Modular high-frequency and high-voltage X-ray generator; High-frequency inverter power.(5.0KW, 120KV, 100mA, 50KHZ)                                   one set

2,Innovative mobile X-ray photography Main frame                        one set

3,Mobile X-ray photography control system                               one set

4,Symmetric Adjustable beam limiter with light                            one set

5,Remote controller  ( Hand hold  controller  and Wireless Microwave control ,the distance is 20 meters )      one set

6. 12” X 15” Image Intensify , Cassette , Grid                          one set

7,General spare parts                                                 Several

2)  Options : JT-X152 Table for Mobile X ray Equipment and Upright Bucky Stand

A. JT-X152 Table ( Special for High Frequency Mobile X ray machine )

 The size of PLX152 is 2000mm×700mm×500mm, cassette movement range is 1680mm . Low bed to facilitate the patient up and down, Longitudinal center of the bed frame with the cassette center line are consistent. To make the center of symmetry when photograph,and the movement range of cassette get larger And have manual brakes convenient location, bed body can 360 ° moving flexible

B. Upright Bucky Stand

The height : 1768 mm

Movement range of up and down : 470mm~1468 mm

Grid Density :103L/INCH

Grid Ratio : 10:1

Focus Distance : 150cm ,

Features:  with Stationary Filter line, 18” X18” Can take maximum 17”X17” X ray film
