Электрическая проволока Торцевая крышка пластиковая Термоусаживаемая Крышка для электрического

Электрическая проволока Торцевая крышка пластиковая Термоусаживаемая Крышка для электрического

Категория: Колпачки для кабелей >>>
Поставщик: Guangzhou,Kaiheng,K&S,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-18-2025	0.12 $*	0.14 $*
Aug-18-2025	0.37 $*	0.96 $*
Jul-18-2025	0.81 $*	0.81 $*
Jun-18-2025	0.46 $*	0.59 $*
May-18-2025	0.80 $*	0.81 $*
Apr-18-2025	0.56 $*	0.76 $*
Mar-18-2025	0.5 $*	0.78 $*
Feb-18-2025	0.37 $*	0.82 $*
Jan-18-2025	0.78 $*	0.75 $*

Характеристики

Product Description

HSEC offers an economical means of sealing the end of power cable with a completely Watertight seal.The internal surface of the end cap has a layer of spiral coated hot melt adhesive,which retains its flexible properties after recovery.HSEC is recommended for application both in open air and on underground power distribution cables with PVC.Lead or XLPE sheaths.

Property	Test Method	Typical Data
Operating temperature	IEC 216	-55 to +110 ℃ ℃
Tensile strength	ASTM D 638	>14MPa
Elongation at break	ASTM D 638	>400%
Density	ASTM D 792	1.05
Elongation at break after aging	150 /168hrs.℃	>300%
Dielectric strength	IEC 243	>15kV/mm
Volume resistance	IEC 93	>1014 Ω. cm

Feature:

Effectively offering protection against oxidation,Ozone,UV-rediation etc.
Coated with hot melt adhesive to ensure environment seal
Easily to fit into the cable end
Minimun fully shrink temperature :120℃.

^{Order ref.No.}	As supplied (mm)			After recovery(mm)			Cable Diameter(mm)
^{Order ref.No.}		D(Min)	D(Max)	D(Max)	A(±10%)	L(±10%)	Cable Diameter(mm)
EC-12/4	12	4.0	15	40	2.6	4 -10
EC-14/5	14	5.0	18	45	2.2	5 -12
EC-20/6	20	6.0	25	55	2.8	6 -16
EC-25/8.5	25	8.5	30	68	2.8	10 - 20
EC-35/16	35	16.0	35	83	3.3	17 -30
EC-40/15	40	15.0	40	83	3.3	18- 32
EC-55/26	55	26.0	50	103	3.5	28 48
EC-75/36	75	36.0	55	120	4.0	45 -68
EC-100/52	100	52.0	70	140	4.0	55 -90
EC-120/60	120	60.0	70	150	4.0	65-110
EC-145/60	145	60.0	70	150	4.0	70-130
EC-160/82	160	82.0	70	150	4.0	90-150
EC-200/90	200	90.0	70	160	4.2	100-180
