Product Type: | Offset Printing CTCP UV Plate |
Gauge: | 0.15/0.20/0.25/0.30/0.40mm |
Substrate: | Electronically grained and anodized aluminum substrate |
Application: | commercial Sheetfed and rotary press printing |
Spectral sensitivity: | 350-460mm UV light, especially 400-410mm UV laser |
Exposure energy: | 30-35mW(Cron UV-4632CI type platesetter , parameters 1000 rpm). |
Resolution: | 2-98%@250lpi(Platesetters in different resolution will have difference). |
Safelights: | yellow light handing |
Working conditions: | Operating temperature 21-25 ℃ (room temperature), relative humidity 40-60% |
Storage condition: | Storage temperature:15-27℃,relative humidity: 25-60%,shelf life:18 months under recommended storage condition |
Run length: | Up to 150,000 impressions without baking. Actual run length will have differences according to press/paper/ink/chemicals conditions |
