Полностью автоматическая высокоскоростная машина для флексографской печати на гофрированном
- Категория: Штамповысекальная машина для печати и прорезки на картоне >>>
- Поставщик: Dongguang,Xinglong,Packaging,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 35700.94 $* | 37485.62 $* |
| Aug-17-2025 | 35400.50 $* | 37170.63 $* |
| Jul-17-2025 | 29700.55 $* | 31185.36 $* |
| Jun-17-2025 | 34800.81 $* | 36540.55 $* |
| May-17-2025 | 30300.68 $* | 31815.17 $* |
| Apr-17-2025 | 34200.48 $* | 35910.51 $* |
| Mar-17-2025 | 33900.88 $* | 35595.18 $* |
| Feb-17-2025 | 33600.13 $* | 35280.7 $* |
| Jan-17-2025 | 33300.90 $* | 34965.94 $* |
Характеристики
Product Description
Main mechanisms performance
1. Adopt lead edge feeding system . Adjust wind volume according bending degree to ensure feeding paper smoothly 2. The rubber
roller with air cylinder device ,feeding accurately , stably , not destroy paperboard strength if the feeding space is very small.
3. The left and right side baffles adopt electric control with data display(options: pneumatic lifting device ) the back baffle
box adopt electric adjustment , the front baffle space by manual adjustment.
4. Equipped with colors touch screen take 360 degree set to die roller , display product speed and set production quantity .
5. The rubber roller adopt mechanical control the position move left and right .the movement distance is 40mm.
6. The space of rubber roller with die roller adopt automatic looking device .and with air cylinder can adjust quickly ,reduce
rubber wear ,prolong use lift.
7. With speed compensation device make rubber roller rotate with die roller ,make the surface speed of the rubber cushion is
completely controlled by dies .The shape of the carton will absolutely equal to the dies.
8. With rubber repair device ,the rubber can be used after repaired.
9. All of rollers are made of good quality steel .Surface be grinded ,tempering,hard chromed plate.
10. Drive roller used good quality alloy steel ,after heat treatment ,be grinded .Gear closed cycle spray lubrication ,automatic
balance engine oil device ,keep every unit oil level is equal.
11. Main motor use frequency converter adjustment.
1. Adopt lead edge feeding system . Adjust wind volume according bending degree to ensure feeding paper smoothly 2. The rubber
roller with air cylinder device ,feeding accurately , stably , not destroy paperboard strength if the feeding space is very small.
3. The left and right side baffles adopt electric control with data display(options: pneumatic lifting device ) the back baffle
box adopt electric adjustment , the front baffle space by manual adjustment.
4. Equipped with colors touch screen take 360 degree set to die roller , display product speed and set production quantity .
5. The rubber roller adopt mechanical control the position move left and right .the movement distance is 40mm.
6. The space of rubber roller with die roller adopt automatic looking device .and with air cylinder can adjust quickly ,reduce
rubber wear ,prolong use lift.
7. With speed compensation device make rubber roller rotate with die roller ,make the surface speed of the rubber cushion is
completely controlled by dies .The shape of the carton will absolutely equal to the dies.
8. With rubber repair device ,the rubber can be used after repaired.
9. All of rollers are made of good quality steel .Surface be grinded ,tempering,hard chromed plate.
10. Drive roller used good quality alloy steel ,after heat treatment ,be grinded .Gear closed cycle spray lubrication ,automatic
balance engine oil device ,keep every unit oil level is equal.
11. Main motor use frequency converter adjustment.
Product Paramenters
model | FAY1224 |
feed type | light pressur lead edge |
design speed | 200 pcs/min |
working speed | 160-180 pcs |
power | 30kw |
Printing precision | +-0.5mm |
Wall thickness | 50mm |
Max feeding paper siz(mm) | 1200*2400 |
Max effective printing size(mm) | 1200*2200 |
printing roller dia. | 410mm |
certificate | CE,BV |
