Настенная нагревательная и охлаждающая вентиляторная катушка
- Категория: Кондиционеры >>>
- Поставщик: Guangdong,Folansi,Energy,Saving,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.60 $* | 0.74 $* |
| Aug-15-2025 | 0.2 $* | 0.22 $* |
| Jul-15-2025 | 0.59 $* | 0.38 $* |
| Jun-15-2025 | 0.93 $* | 0.97 $* |
| May-15-2025 | 0.29 $* | 0.39 $* |
| Apr-15-2025 | 0.7 $* | 0.54 $* |
| Mar-15-2025 | 0.30 $* | 0.23 $* |
| Feb-15-2025 | 0.65 $* | 0.69 $* |
| Jan-15-2025 | 0.16 $* | 0.98 $* |
Характеристики
HIGH WALL MOUNTED FAN COIL UNIT | |||||
Model(2 tube system) | FBG -34BM | FBG - 51BM | |||
power supply | 220V,50Hz,1Ph | ||||
air volume | H | m3/h | 340 | 510 | |
M | 280 | 380 | |||
L | 180 | 260 | |||
cooling capacity | TH | H | W | 1800 | 2700 |
BTU/h | 6142 | 9212 | |||
SH | W | 1350 | 2025 | ||
BTU/h | 4606 | 6909 | |||
TH | M | W | 1476 | 2214 | |
W | 978 | 1399 | |||
SH | L | W | 1098 | 1647 | |
W | 649 | 960 | |||
heating capacity | H | W | 2700 | 4050 | |
M | W | 2146 | 3219 | ||
L | W | 1512 | 2268 | ||
noise | H | 0Pa | dB(A) | 37 | 39 |
power input | H | 0Pa | W | 30 | 38 |
waterflow volume |
| m3/h | 0.31 | 0.46 | |
water pressure dropping | kPa | 12 | 14 | ||
dimension of water(in & out)connection pipe | in | ZG1/2" | ZG1/2" | ||
out | ZG1/2" | ZG1/2" | |||
coil | type | high efficient copper pipe to wear Hydrophilic aluminum coil | |||
The maximum pressure | MPa | 1.6 | 1.6 | ||
dimension of water drain pipe | mm | 16 | 16 | ||
unit dimennsion | L×W×H | mm | 795*285*215 | 795*285*215 | |
unit weight | kg | 11.2 | 11.2 | ||
