Роторный потенциометр rk 09 9 мм b50k R0903N1PA1 alpha 500k 100k 1k 20k
- Категория: Потенциометры >>>
- Поставщик: Changzhou,Kennon,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.53 $* | 0.53 $* |
| Aug-18-2025 | 0.22 $* | 0.33 $* |
| Jul-18-2025 | 0.49 $* | 0.89 $* |
| Jun-18-2025 | 0.27 $* | 0.0 $* |
| May-18-2025 | 0.75 $* | 0.88 $* |
| Apr-18-2025 | 0.13 $* | 0.57 $* |
| Mar-18-2025 | 0.85 $* | 0.10 $* |
| Feb-18-2025 | 0.49 $* | 0.16 $* |
| Jan-18-2025 | 0.98 $* | 0.20 $* |
Характеристики
9mm b50k Rotary alps Potentiometer R0903N1PA1 alpha 500k 100k 1k 20k 10k 9mm rotary potentiometer
9mm b50k Rotary alps Potentiometer R0903N1PA1 alpha 500k 100k 1k 20k 10k
9mm rotary potentiometer
Product Description
Mechanical characteristics:
Total rotation angle:300°±10°
Rotation torque: 1~8mN.m
Shaft stop strength: 0.4Kgf.cm
Push pull strength: 5Kgf
Electrical characteristics
Total resistance: 5KΩ ~500K Ω
Resistance taper: A,B,C
Rated wattage: 0.05W
Resistance tolerance: ±20%
Rotational noise:≤47mV
Tracking error : 0~-40dB ±3dB
Max,operating voltage: B:50VAC other than B:25V AC
Insulation resistance: More than 100MΩ at DC 250V
Residual resistance: R≥250Kohm 0.1% max. of total resistance
250KΩ>R> 10KΩ 20Ω max 10 max
10KΩ≥R
Durability: 10000 cycles
Standard: ISO9001:2000 ISO14001:2004 measure up ROHS
Origin: Changzhou,Jiangsu, P.R China
