Графическая пленка AGFA фотосъемка HN

HNS Graphic Art Films are designed for image setters and scanners.
HNS Graphic Art Films are designed for image setters and scanners. Spectral sensitivity: HeNe laser and red laser diode (630-670nm) Emulsion coated on a 0.10 mm antistatic polyester base

*Wide exposure and development latitude

*High density

*Excellent image quality

*High contrast

*Good linearity

*Antistatic before and after processing

*High processing speed

*Low replenished rate

Applicable Models

Brand name	Model of machine	Light source
SCREEN	FT-R3050/5055	633 nm /650 nm
Fuji's Luxel	9000/6000	650 nm
ECRM	VRL series & Mako	670 nm
Creo	Dolev450/8000v/8000v2	632.8 nm
Heidelberg	Signasetter Pro	632.8 nm
Heidelberg	Herkules Pro	670 nm
Heidelberg	ULTRE5800	670 nm
AGFA	SelectSet Avanbtra series	650nm
Panther	Panther Pro46	670 nm
Cron	ACF series	650 nm
Eastcom	DX series	650 nm

Product Details Show

Sizes Available

390mmX60m	610mmX60m
406mmX60m	660mmX60m
457mmX60m	813mmX60m
508mmX60m	838mmX60m
838mmX60m	914mmX60m

Other sizes are also available as required.

Unpacking

The film for daylight loading can be loaded in the special cassette of laser image output machine under daylight.

The film for darkroom loading should be loaded in the special cassette of laser image output machine under special dark green light or under totally dark.

Be careful when operating in order to prevent film damaged from friction, folding, oil and fingerprint, etc.

Storage

Store the Imagesetting films in a cool and dry place.

Storage temperature is not higher than 20°C and RH no more than 65%. Being too warm and humid will shorten the films shelf life.

Avoid radiation or corrosion of other substances and sunshine.
