USE:
Fluoroscopy
Digestive track spot film radiography

General radiography
Filter-ray device radiography



Main Characteristics:
1. Single bed and single tube
2. Design according to the electric medhanism of middle-size machine. The function is full and reasonable.
3. The high-tension system is of march-past structure. Equipped with afullwave rectification high-voltage generator and ifdependent X-ray tube unit, with large output power and reliable and stable operation.
4. Supply voltage V, roentgenoscopy, photograpy kV and stepless adjustable.
5. Equipped with the manostat for filament of X-ray tube and the spacecharge compensator as to ensure the stable and accurate output.
6. Equipped with the capacity limitation and protection circuit and kV mA s interlock limitation and protection.
7.Adopt the digital circuit timer, grade according to R10 prioritycoefficient and can control time exactly.
8. Diagnostic bed id of electric back rotation and is equipped with vibrating filter-ray device.
9. The spot film device of fluoroscent screen can hole the film jecket of various sizes and can make the photograpy of full-film and half films separately.
10. The upright post has the bottom track only, which is easy while instalation.



Power supply	Adjustable range	With power supply 380V  340V—420V
		With power supply 220V  195V—250V
Fluoroscopy	Adjustable range of tube voltage	50~95kV (Can adjust continuously)
	Adjustable range of tube current	0.5~5mA (Can adjust continuously)
Radiography	Adjustable range of tube voltage	50~100kV (Can adjust continuously)
	Adjustable range of tube current	Small focus: 50mA
		Big focus: 50, 100, 150 and 200mA
	Tube current of spot-film	150mA (fix)
	Adjustable range of time	0.04~6.3s   23 grades together
High-voltage Generator unit	Max. DC output voltage	100kV
	Max. DC output current	200mA at instant     5mA at running
X-ray tube	Model	XD51-20.40/100
	Focus	1mm×1mm      2mm×2mm
	Rotary angle	+90°~0°~-5°
	Move range of gastrointestinal spot-film device (fluorescent screen)	Pressure direction:            300mm
		Horizontal direction: the center of diagnostic bed moves left (right)		±80mm
		Vertical direction:              400mm
Diagnostic bed	Ray-filter for fluoroscopy	Manual single blade
	Distance between focus and bed face:
	At fluoroscopy and gastrointestinal radiography:    400mm(fix)
	Ray-filter tube (device) for radiography (fix X-ray field)	Big (rectangle)	14”×17”	Distance between focus and film=1m
		Middle (rectangle)	10”×12”
		Small (circle)	φ5”
