2019 уличный старомодный мобильный бар для

Note:
1.Body dimension is not fixed as above, you can have your own size and design. Customization is available.
2.Brake is included once the body length is no shorter than 400CM (13.1ft). Shorter size can have the brake system installed at certain cost. please contact us for details.
3.Any uncertain trailer design, don't be hesitate to talk to us.

Trailer standard configuration introduction:

Chassis:
* Integral steel frame construction: square tube :100*50*4mm + 60*40*2mm
* Suspension components: 5-leaf springs with axle; treated with rust resistant protective coating
* Standard speed(Kilometer/hour): 40KM/H. Special made chassis is optional for higher speed (80-100KM/H)

Body:
* Wall frame is welded by square tubes: 40*60*2mm
* external wall is high quality galvanized sheet with colorful painting.(contact us for the color book)
* middle layer is 5cm heat insulation
* internal wall is High quality stainless steel
* one selling window available in front, normial size is 2000*1100mm. Other window size is available.
* with waterproof sealing strip

Electric accessories:
* General control, automatic power failure protector
* Two rows of led spotlights on the ceiling and selling window
* All standard sockets,quantity as needed
* high visibility tail light signal system.(brake, turn, back)

Floor:
*3 layers: 2mm non-slip embossed aluminum + 10mm plywood or pvc +1mm galvanized sheet

Wheel:
* double axles(four wheel); 14 or 15 inch tires; one guide whee

Water sinks:
* Double sinks with hot and cold water taps. 3 compartment sink is optional
* A fresh water tank, a waste water tank (25L/tank standard). Other capacity tank is available.
* 12V mini water pump
* on/off control switch

How to buy a desired trailer ?

1. List out needed equipment which will be used in the trailer, then have their size.

We can provide equipment as well
2. Decide the perfect trailer size you need based on Step 1
3. We offer the quote and drawing (2D/3D) based in Step 2 then we keep negotiating till you are satisfied.
4. We start building the trailer once deposit received. Trailer progress will be reported via pictures or vedios.
5. Balance paid when trailer is finished.

We or you arrange the shipping based on transaction terms
6. For more information about getting the trailer, please let us know,we would like to help more!
