Китайская Фабрика 6 AWG до 30 медный провод силиконовый изолированный Электрический

Описание и отзывы

Трекер стоимости

Характеристики

This link price is for silicone wire of 6awg, if you want other wires and size, kindly send us an inquiry

Product Name	China factory 6 AWG to 30 AWG copper wire silicone insulated electric cable
Cable Length Per Roll	100/200/300M
Use	Camera, automobile machine ,Controller Switch ,Lithium Battery,Computer,MP3 / MP4 Player,Video Game Player Etc
Awg	4awg - 30 awg
Conductor Specification	3200/0.08TS for 6 awg
Insulated Material	Soft Silicone
Color	Black red Pink Green White Blue Or Customized Color
OEM	Available
Material for Conductor	Pure Copper ,Tinned Copper,Copper Clad Aliuminum
Sample	4awg -10awg 3meter Free,  12awg-30awg 10meter Free



Each Size Specification For Soft Silicone Wire

Conductor				Insulation		Unit length
Size	Construction	Diameter	Section	Nominal Thickness	Over Diameter	(M)(Ft)
(AWG)	(No./mm)	(mm)	(mm²)	(mm)	(mm)	Meter
30	11×0.08	0.3	0.08	0.55	0.8	300
28	16×0.08	0.36	0.12	0.38	1.2	300
26	30×0.08	0.46	0.15	0.55	1.5	300
24	40×0.08	0.61	0.2	0.55	1.6	300
22	60×0.08	0.72	0.3	0.49	1.7	300
20	100×0.08	0.92	0.5	0.44	1.8	300
18	150×0.08	1.13	0.75	0.59	2.3	200
16	252×0.08	1.47	1.25	0.77	3	200
14	400×0.08	1.78	2	0.83	3.5	200
12	680×0.08	2.41	3.4	1.05	4.5	100
10	1050×0.08	2.9	5	1.3	5.5	100
8	1650×0.08	3.5	8.25	1.5	6.5	100
6	3200×0.08	5.2	16	1.65	8.5	100
4	5000×0.08	7.2	25	2.4	12	50

If you have any other questions, please click here to " send an inquiry "

1. Q: Are you trading company or manufacturer ?

A: We are factory. We always leads the new trend of modern society, actively adopts new materials and new technologies, and continues to write a new page of glorious history.



2. Q: How does your factory do regarding quality control?

A: "Quality is our culture." We always attach great importance to quality controlling from the very beginning to the very end..



3. Q: Do you provide samples ? Is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay shipping charge.



4. Q: How long is your delivery time?

A: Normally  it is 10-20 days, it will depend on quantity.



5. Q: What is your terms of payment ?

A: Payment 30% T/T in advance, balance before shippment. we can accept Trade Assurance/Paypal/Western Union etc.



6. Q: After sales service:

A: All of our products are made by top quality ,we will check the quality before deliver to you. If there any problem on quality .We will solve the problem for you in the first time, and will come up with the most suitable solution to solve the after-sales problem.



If you have any other questions, please click here to '' send an inquiry ''
