Код Тип B RCCB Американская классификация проводов 2р 4P 63 ампер 10KA 230V 400V 30mA остаточный ток выключателя
- Категория: Circuit Breakers >>>
- Поставщик: Wenzhou,Tongou,Electrical,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 119.87 $* | 125.82 $* |
| Aug-15-2025 | 118.67 $* | 124.14 $* |
| Jul-15-2025 | 99.5 $* | 104.58 $* |
| Jun-15-2025 | 116.95 $* | 122.12 $* |
| May-15-2025 | 101.83 $* | 106.39 $* |
| Apr-15-2025 | 114.63 $* | 120.28 $* |
| Mar-15-2025 | 113.15 $* | 119.17 $* |
| Feb-15-2025 | 112.94 $* | 118.81 $* |
| Jan-15-2025 | 111.48 $* | 117.61 $* |
Характеристики
Product Description
Type B RCCBs, in addition to normal AC, can detect high frequency AC and pure DC earth leakage currents. Reducing the risk of fire and/or electrocution through automatic disconnection of the electrical supply relies on the selection of the correct type of RCCB.
View 'B' Type
Applications requiring 'B' types include:
EV & PV installations
Frequency converters
UPS installations
High-frequency power converters
Building site power supply cabinets
Technical Data
1. Provides protection against earth fault/leakage current and function of isolation.
2. High short-circuit current withstand capacity.
3. Applicable to terminal and pin/fork type busbar connection.
4. Equipped with finger protected connection terminals.
5. Automatically disconnect the circuit when earth fault/leakage current occurs and exceeds the rated sensitivity.
6. Independent of power supply and line voltage, and free from external interference, voltage fluctuation.
| Item | RCD |
| Model | B |
| Pole | 2P,4P |
| Rated making and breaking capacity:630A | Rated voltage: 240/415V AC |
| Rated frequency: | 50/60Hz |
| Rated residual operating current | 30mA |
| Tripping duration | instantaneous tripping 0.1s |
| Standard | IEC CE CB ISO9001 TUV |
| Rated current(A) | 16,25,32,40,63,80,100 |
| Installation | 35MM DIN RAIL |
Product Details
Company Information
FAQ
1.Are you a factory or trading company?
We are a factory founded in 1993 and have more than 20 years of experience in international trade.
2.What’s your main product?
Our main products are MCB,RCD, RCBO, Time Switch,Relay,Distribution box,Junction box and so on.
3:Do you have a catalogue? Can you send me the catalogue to have a check of all your products?
Yes, We have product catalogue. Please contact us on line or send an Email to sending the catalogue.
4.Can I visit your factory?
We have over 4500 square meters of workspace and sincerely welcome your business visit.
5.Any quality guarantee or after-sales service?
All the products have 2-5 years’ Guarantee. If any quality complaint , we will give out solution within 5 days.
