Topsky Акционная цена air cell 156 158 166 мм Mono PERC power bank солнечные
- Категория: Solar Cells >>>
- Поставщик: Shenzhen,Topsky,Energy,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.43 $* | 0.21 $* |
| Aug-19-2025 | 0.57 $* | 0.25 $* |
| Jul-19-2025 | 0.12 $* | 0.92 $* |
| Jun-19-2025 | 0.78 $* | 0.89 $* |
| May-19-2025 | 0.75 $* | 0.10 $* |
| Apr-19-2025 | 0.54 $* | 0.52 $* |
| Mar-19-2025 | 0.31 $* | 0.87 $* |
| Feb-19-2025 | 0.9 $* | 0.84 $* |
| Jan-19-2025 | 0.35 $* | 0.49 $* |
Характеристики
Topsky Promotion price air cell 156 158 166 mm Mono PERC power bank solar cells
Mono-Crystalline Silicon Solar Cell:
| Dimension | 156.75 mm X 156.75 mm ± 0.25 mm |
| Thickness | 200 µm ± 30 µm |
| Front | Five 0.8mm wide bus bars(silver) with distance 31.2mm, alkaline texturized surface with dark blue silicon nitride AR coating |
| Back | 1.4mm wide silver/aluminum soldering pads,aluminum back surface field |
TYPICAL ELECTRICAL CHARACTERISTICS:
| Efficiency (%) | 20.6 | 20.8 | 20.9 | 21.0 | 21.1 | 21.2 | 21.3 | 21.4 | 21.6 |
| Pmax (W) | 5.033 | 5.082 | 5.106 | 5.131 | 5.155 | 5.180 | 5.204 | 5.228 | 5.277 |
| Voc (V) | 0.661 | 0.664 | 0.665 | 0.666 | 0.667 | 0.667 | 0.668 | 0.668 | 0.668 |
| Isc (A) | 9.646 | 9.697 | 9.722 | 9.748 | 9.773 | 9.798 | 9.824 | 9.849 | 9.900 |
| Vmp (V) | 0.549 | 0.551 | 0.552 | 0.553 | 0.554 | 0.555 | 0.556 | 0.557 | 0.559 |
| Imp (A) | 9.162 | 9.217 | 9.244 | 9.272 | 9.299 | 9.326 | 9.354 | 9.381 | 9.436 |
| Data under standard testing conditions (STC) : 1,000W/m2,AM1.5 , 25℃ , efficiency tolerance : average +0.3%/-0.1% absolute. | |||||||||
Pre sale:
1. Our sales representative and engineer work together to answer your questions and offer solution for free
2. We choose the best product for you to make sure it worth its real value
3. We design the best solution with good perfomance for you,manwhile save every cent of your money.
After sale:
1. We provide 10 years Warranty for the product, 10 years warranty for 90% power production ,25 years warranty for 80% power production.
2. We Topsky Energy are authorized distributor of Suntech brand panels---one of the most famous tier-1 brand manufacturer in the world. We welcome your any inquiry.
