No.

Name

Function

(1)

EARTH

Connect to shell of testing object or ground

(2)

GUARD

Connect to high pressure retaining rings of testing object, to eliminate the effect of surface leakage current.

(3)

LINE red bar

High voltage output, connect to high voltage conductor of testing object(Probe, clamp and hook)

(4)

Mechanical header

Top is green,green represent GΩ

Bottom is red,red represent MΩ

(5)

Measurement range indicator

Red light, reads on the lower dial; while green light, reads on the upper dial

(6)

Led display

Display test resistance, type, voltage, time, historical test data timing

(7)

Mechanical zero

Adjust the position of the mechanical pointer, align it with the infinity line ∞ while power off.

(8)

Test function keyboard

Select the test category, bring up the view history data, and set the current time

(9)

High voltage output indicator

Light on refer to high voltage output

(10)

Battery indicator

When the lamp is flashing, the instrument is under voltage and needs to be charged.

(11)

Power switch and voltage selection knob

Working power off, output many gears

(12)

Charger interface

Power by 220V AC±15%

(13)

High voltage output

Press right to rotate locking high pressure output, and left to rotate to remove high pressure output
