Характеристики

QC Model 55 Tons Ship-To-Shore Double Trolley Quay Crane

Product Description

 Unloader Ship Crane Basic specifications:

1. Unloader Ship Crane Capacity:  40t (Under spreader)

2. Unloader Ship Crane Lifting height: 22m above rail & 12m below rail

3. Unloader Ship Crane Out reach distance: 35m

4. Unloader Ship Crane Back reach distance: 12m

This unloader ship crane quay crane is mainly used for loading & unloading different containers  from boat to shore or from shore to boat.

Contact us for more information!

QC Model 55 Tons Ship-To-Shore Double Trolley Quay Crane

It mainly consists of metal structure, four big mechanism,  winding method, frame system, auxiliary devices, etc.

Unloader Ship Crane Four Big Mechanism Overview:

1. Hoisting mechanism for unloader ship crane

QC Model 55 Tons Ship-To-Shore Double Trolley Quay Crane

2. Luffing mechanism for unloader ship crane
QC Model 55 Tons Ship-To-Shore Double Trolley Quay Crane

3. Trolley traveling mechanism for unloader ship crane

QC Model 55 Tons Ship-To-Shore Double Trolley Quay Crane



1). Buffer for reducing pressure



2). Trolley frame



3). Trolley pulley group



4).  Trolley separating unit



5). Driving system



6). Control room



7). Trolley wheel group







4. Crane traveling mechanism for unloader ship crane

QC Model 55 Tons Ship-To-Shore Double Trolley Quay Crane

5.Unloader ship crane detail parts overview:

QC Model 55 Tons Ship-To-Shore Double Trolley Quay Crane

Unloader Ship Crane Advantage:

1. Variable speed, Soft starter, Slipring motors;

2. Wireless Radio Remote control;

3. Shrouded DSL system for power feeding;

4. Flameproof, Cabin Operated;

5. PLC automatic Control system;

6. High quality carbon steel Q345;

7. Port crane design adopt european technology;

8. All electrical applicance adopt china first-class brand, Siemens,Schneider or according to your demands.

Contact us for more information!

QC Model 55 Tons Ship-To-Shore Double Trolley Quay Crane

QC Model 55 Tons Ship-To-Shore Double Trolley Quay Crane



Technical Parameters for Unloader Ship Crane

Rated Load Under Spreader   40t
Under Headlock   50t
Distance parameter Out Reach   35m
Rail Gauge   16m
Back Reach   12m
Hoisting Height Above rail   22m
Below rail   12m
Speed Hoisting Rated load 30m/min
Empty Spreader 60m/min
Trolley travel   150m/min
Gantry travel   30m/min
Boom hoist   6min/single stroke
Spreader Skew Left and right inclination   ±3°
Fore-and-aft inclination   ±5°
Plane rotating   ±5°
Wheel Load Working condition   400KN
Non-working condition   400KN
Power  10kV 50 Hz

 Click here to get more specification and quotation!
