OEM автомобильный Gps-трекер для людей с GPS-трекером последовательным

OEM автомобильный Gps-трекер для людей с GPS-трекером последовательным

Категория: GPS Tracker >>>
Поставщик: Shenzhen,Bainianxing,Technology,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-17-2025	0.47 $*	0.98 $*
Aug-17-2025	0.7 $*	0.72 $*
Jul-17-2025	0.21 $*	0.44 $*
Jun-17-2025	0.68 $*	0.91 $*
May-17-2025	0.88 $*	0.42 $*
Apr-17-2025	0.95 $*	0.85 $*
Mar-17-2025	0.57 $*	0.7 $*
Feb-17-2025	0.62 $*	0.80 $*
Jan-17-2025	0.76 $*	0.91 $*

Характеристики

Product Description

This product GPS receiver GPS module GPS antenna can be customized according to customer requirements, we can make it straight head, elbow style, 4PIN connector etc.

Please contact sales befor order! Thank you!

Product Features.

1.Supports quad bands, i.e. 850/900/1800/1900MHz, universal in the world.
2.Wide Input Voltage:6-36V DC.
3.Supports single positioning and feedbacks position via GPRS at setting times.
4.Supports vehicle positioning and tracking.
5.Supports ACC status checking and vehicle status notifying.
6.Use relay to remote control the vehicle..
7.Use SOS button for SOS call.
8.Use external MIC to monitor remotely

Alarm Types :
Vibration Alarm(Optional)
Collision / falling Alarm(Optional)
Speed Alarm
Geo-fence Alarm
Power disconnect Alarm
SOS Alarm(need SOS Cable)

Function Extension:
Default interface: Microphone input port for remote monitoring
Can be extended: ADC input port, used for temperature and oil detection
Can be extended: External lithium battery port, used for long battery life
Can be extended: UART expansion port (TTL level), RS232 serial port expansion application

Environment for use :

1.Limited working temperature:-20°C~80°C
2.Storage temperature:-45°C~90°C
3.Humidity:<95%
4.Atmospheric pressure:86kPa~106kPa
5.Make sure the terminal is installed in rainproof
and snow-proof places.
6.Battery: 200MAh battery

Working Voltage:	12VDC/24VDC
Standby Current	<3mA
Work current :	<120mA
GPS positioning accuracy	15M
GSM positioning accuracy	100M
GPS Frequency	1575MHz
GSM Frequency :	850/900/1800/1900MHz
Hot/warm/cold start time :	<3S,<1S,<60S
Dimensions (mm) :	LWH: 56.5 X 47 X 24.6
Weight :	45 g

With 10 years of gps industry experience along with excellent quality, advanced services and competitive prices, Bainianxing has won numerous customers' trust and support.

3000㎡ dust-free workshop, brand new high-precision equipment, fully automated production line, ISO9001, ISO14001 environmental management system certification.

With the most advanced Fuji NXT3 machine and JUKI K-RS1/3010/3020vam SMT high-speed module patch production line, each line can support 70,000 points per hour.

GPS PCB Assembly

Professional Quality Checking

Support OEM GPS Receiver

Advanced High Precision Machine
