Макси автономный мини-ибп 220 в ва с батареей для резервного копирования

MODEL

N600VA

N800VA

N1000VA

N1200VA

Rated power

360W

480W

600W

720W

INPUT

Input voltage range

220V:145~290Vac

Input frequency range

45Hz / 65Hz (Auto sensing)

AVR

3 steps of AVR, CPU controlled

OUTPUT

Output voltage range

220V:200~255Vac

Output frequency (DC mode)

  50±0.5Hz / 60±0.5Hz (Auto sensing)

Wave form

PWM (DC Mode)

Transfer time

Typical 2~6ms, Max.10ms.

BATTERY

QTY & capacity of battery

1x12V/7Ah

1x12V/9Ah

2x12V/7AH

2x12V/9AH

Charging time

4~6 hours  to 90% capacity

PROTECTION & FUNCTION

PROTECTION

1. Battery low voltage protection
2. Overload protection
3. Short circuit protection

FUNCTION

1. Auto re-start when AC recovers
2. Mute setting
3. Automatic charging (off mode charging)

MANAGEMENT

RJ45/11 & USB

Optional

PHYSICAL

UPS dimension WxDxH(mm)

305x85x141

305x85x141

330*122*192

330*122*192

Gross weight (1pc, kg)

4.9

5.2

9.2

9.8

Net weight (1pc, kg)

4.5

4.8

8.7

9.3
