Классический резиновый v-образный
- Категория: Ремни резиновые >>>
- Поставщик: Xingtai,Boshuo,Trading,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.64 $* | 0.1 $* |
| Aug-16-2025 | 0.48 $* | 0.34 $* |
| Jul-16-2025 | 0.94 $* | 0.34 $* |
| Jun-16-2025 | 0.78 $* | 0.36 $* |
| May-16-2025 | 0.64 $* | 0.37 $* |
| Apr-16-2025 | 0.63 $* | 0.3 $* |
| Mar-16-2025 | 0.57 $* | 0.9 $* |
| Feb-16-2025 | 0.64 $* | 0.30 $* |
| Jan-16-2025 | 0.79 $* | 0.64 $* |
Характеристики
We are the world's top supplier of V-belts. Our main products are V-ribbed belts, automotive timing belts, industrial timing belts, V-belts, toothed belts, etc. Please tell us your needs and we will give you the best service.
Products Description
Our advantage
-- Our products use a new production process
-- Our products can be clothed on the top layer to increase life
-- We are factories, so the price is cheap
-- The main material is oil-resistant and high-temperature-resistant composite rubber
-- We have cooperation with major markets and can provide common models
Our advantage
-- High transmission efficiency
-- Low noise
-- Low elongation and high load
-- Long life, not easy to wear
-- Oil resistant and high temperature resistant
-- Low noise
-- Low elongation and high load
-- Long life, not easy to wear
-- Oil resistant and high temperature resistant
-- New vulcanization technology
Name | Material |
Outsice Fabric | Polyester Cotton Canvas |
Tensile Member | Polyester Wire |
Top Rubber | NR CR SBR |
Buffer Rubber | NR CR SBR |
Bottom Rubber | NR CR SBR |
Product Paramenters
Classical V belt:
Type | TOP Width | Pitch Width | Height | Length Range | Angle |
Unit | mm | mm | mm | mm | |
M | 10 | 8.5 | 6 | 400—3000 | 40° |
A | 13 | 11 | 8 | 400—8000 | 40° |
B | 17 | 14 | 11 | 400—12000 | 40° |
C | 22 | 19 | 14 | 990—18000 | 40° |
D | 32 | 27 | 19 | 2200—18000 | 40° |
E | 38 | 32 | 23 | 2200—18000 | 40° |
Narrow V belt:
Type | TOP Width | Pitch Width | Height | Langer Range | Angle |
Unit | mm | mm | mm | mm | |
SPZ(FM) | 10 | 8 | 8 | 400—4000 | 40° |
SPA | 13 | 11 | 10 | 600—5000 | 40° |
SPB | 17 | 14 | 14 | 1270—10000 | 40° |
SPC | 22 | 19 | 18 | 1900—18000 | 40° |
3V(9N) | 9.5 | / | 8 | 400—4000 | 40° |
5V(15N) | 16 | / | 13.5 | 1270—10000 | 40° |
8V(25N) | 25.5 | / | 23 | 2540—18000 | 40° |
Recommend Products
Manufacturing Technique
Company Profile
HEBEI BOSHUO AUTO TECH CO.,LTD established in 2014, is specialized in design, research, prodiction and sale of v belt, raw edge v belt, poly v belt, industrial timing belt, auto timing belt etc.
The company is located in Beiding Industrial Zone, the largest rubber production and export base in North China ( closed to the Jing-Shen Expressway and the Zhengding International Airport). There are an area of 5600 square meters, a total asset of 5,000,000RMB and 198 staff including 6 senior engineers and 30 technicians. It has introduced from Japan, Taiwan etc the First-Class technology, the production equipments such as automatic vacuum vulcanizing machine, and advanced testing equipments to assure the leading position in the industry.Our products mainly include v belt, v-ribbed belt, cogged v belt, industral timing belt, auto timing belt etc. we are good at all kind of belts,All of them arecertificated by SQSB and ISO9001. Our products are very popular at home and abroad and we have built up long-term business relationships over 30 countries such as America,Turkey,Russia and Indonesia.With the principle of honesty,Integrity,Mutual-benefit, we hope to estalish a stable relationship with all customers for a bright future.
Product packaging
Title goes here.
* package: bags or cartons
* carton demension: 65*37*26cm
* delivery days: 30 days but also according to you quantity
* Packing information: PP/CARTON, it depends on customer's requirements.
* Shipping condition: LCL, FCL or EXPRESS.
* Quote item: FOB / EXW / CIF / CNF.
* Port: Tianjin Port
* Lead Time: Shipped in 30 days after payment.
* carton demension: 65*37*26cm
* delivery days: 30 days but also according to you quantity
* Packing information: PP/CARTON, it depends on customer's requirements.
* Shipping condition: LCL, FCL or EXPRESS.
* Quote item: FOB / EXW / CIF / CNF.
* Port: Tianjin Port
* Lead Time: Shipped in 30 days after payment.
Client Feedback
FAQ
Q1:Can i order a small quantity of samples?
---- Yes. We can offer you samples at the bulk prices and send them by DHL, TNT. EMS, FEDEX or others according to your requirements.
Q2: How could i know whether the belt fits for my machine?
---- You can tell me which product you are interested in, and i will give you its main sizes. You can also send me drawings or samples, and then we will put them into production at your requests.
Q3: I want to find a supplier for my new products. Can you help me?
---- Yes. Kindly offer me your drawings or samples for analysis.
Q4: How long does it take to make a new product?
---- Usually 10-15 days for drawings and 7 days for samples.
Q5: Can we stencil (or print ) our logo or company name on the belt or package?
---- Yes. Please inform us your logo or design before mass production.
Q6: What is your payment term?
---- T/T 30% deposit and T/T 70% balance before shipment.
Q7: What is your quotation?
---- We will give you FOB price. But EXW, CIF and CNF can also be given according to your demands.
