47 мкФ 900vdc DKMJ Тип Металлизированный Полипропиленовый пленочный конденсатор для ветроэнергетики солнечной энергии фотогальванических

Описание и отзывы

Трекер стоимости

Характеристики

380uf 450vdc DKMJ type metallized polypropylene film capacitor for wind power, solar power, photovoltaic



Application:

1.Used in DC-Link circuits,Can replace electrolytic capacitor

2.Photovoltaic and wind power inverter,high-voltage inverter;

3.High frequency switching power supply,UPS uninterruptible power supply,

EPS emergency power supply,DC regulated power supply;

4.Reactive power compensator SVG.Active power filter APF;EV and HEV's smoothing filter.



Characteristics:

1.It selects the advanced self-healing metalized safety film;

2.Product performance is stable,safety and reliable;

3.Low ESR,which can withstand larger ripple currents;

4.Low ESL,long life.



Technical Specification:

Configuration	Aluminum Shell,Dry,Flame Retardant and Protective Device
Temperarure	-40℃~85℃
Capacitance Tolerance	±5% ±10%
Dissipation Factor	≤0.003(at 100Hz 1V)
Testing Voltage	T-T:1.5Un 10s 25℃ T-C:2Un+1000VAC 60s 25℃
Equivalent Series Resistance(ESR)	0.8~3.0mΩ
Equivalent Series Inductance(Ls)	≤65nH
Expected Service Life	100000 hours



The Above Form Shows Only Part of the Specifications and Can Design on the Basis of Custom Requirement.
