Wiegand распознавание лица rfid наружная клавиатура замок дверные ворота считыватель карт контроль

Reader

4 WG Reader

Alarm output

1 (1-65535 sec)

Alarm input

1

Fire alarm output

1

Fire alarm input

1

Release button

2

Door sensor

2

Lock output

2

Card capacity

54000

Log records

60000

Alarm capacity

10000

Communication

TCP/IP

Door open method

Card

Password

Card+PW

Double card

Fist card

Software

Fire alarm

Release button

Door timer

YES

Model No.

E02.NET

Panel size

210mm*125mm*22mm

New gray cover

214mm*105mm*37mm

Panel color

deep blue

Panel weight

about 250g

Box color

Black

Box weight

1.6KG

Temperature

<=60 degre

Enviroment humidity

10%-95% R.H

Voltage

DC12V

Working current

<=150ma

Rated power

<=10w

Power off protection

10 years

• Support RS485 and TCP/IP access controller at the same time. All of access      controller is using the same software management.

• Support access control and lift access controller and locker access controller management at the same time.


•


• Support 3 kinds of language, and customer can add their own language as their will.


• Simple operation, finishing operation by single click, double click, or right click.


• Real time monitoring like and kinds of alarm, card swiping.


• Support color indicating, using different color to stand for different records.


• Support full screen showing.


• Access,Support Access and SQL server at the same time. The default is Access.


• Three operation authorized: set up users for door, set up door for users, and set up permission teams.


• Support automatic shift arrangement(only SQL available)


• Support daily records, user can check the operation and management history record, easy to manage and system maintenance.
