6806 RS ceramic bearing with ZrO2 bearing



6806 bearing deep groove ball bearing  details:

Hybrid ceramic chrome steel sealed bearing 6806-2RS Bearing with ZrO2 Ceramic Balls Electric motor quality, Bearing 6806-2RS is a popular size that could be used in many application that uses this size 30mm x 42mm x 7mm, each 6806 bearing is closed with 2 Rubber Seals, double sealed and one seal from each side to protect the bearing from dust or any possible contamination, also bearing is pre-lubricated with grease, Bearings 6806 has industrial packaging.

• Item: Double Sealed Ball Bearings Bearings


• Type: Deep groove Radial ball bearings


• Material: Chrome Steel


• Balls: ZrO2 Ceramic


• Closures: Double sealed with rubber seals RS/RS1/2RS1


• Lubrication: Self Lubricated (Grease) 6806RS Bearing


• Radial Clearance: C3


• Quality: Electric motor quality


• Size: 30mm x 42mm x 7mm


• Inner Diameter (ID): 30mm


• Outer Diameter (OD): 42mm


• Width/Height/Bridth (W/H/B): 7mm


• Quantity: One Bearing


• Equivalents: 61806-2RS1/61806RS1 Bearings



     · Single Row Deep Groove Ball Bearings: Single row deep groove ball bearings are the most commonly used bearing type, which can accommodate radial and thrust loads. These bearings can be used at high speeds. The self-aligning capacity of deep groove ball bearings is limited; therefore the bearing locations must be accurately aligned.



· Double Row Deep Groove Ball Bearings Double row deep groove ball bearings have, contrary to their former design, no filling slots. This is the reason that these bearings can accommodate thrust loads in both directions. These are fitted with cages of glass-fibre reinforced polyamide 66 and lubricated with grease. This ball bearing is not suitable, where angular misalignments have to be accommodated



1.brief description of deep groove ball bearing



Deep groove ball bearing is the most common type among ball bearings.The basic structure of deep groove ball bearing include an outer ring,an inner ring, a group of steel ball and a set of cage. Deep groove ball bearing has two types: single row and double rows bearings. The simple structure,convenience,and large production contribute deep groove ball bearing to be the most widely used kind. Deep goove ball bearing is nonseperatable and the design is very simple. This kind of bearing don't need special maintainance

6806 RS ceramic bearing with ZrO2 bearing  technical data:



6806  deep groove ball bearing



Bearing Specifications:
1) deep groove ball bearing type: 6806 2RS



2) ID 30, OD 47, W 7mm



3) Shield/closure: Open / UG, Z ZZ 2RS RS



4) Tolerance: ABEC-1 (P0), ABEC-3 (P6),ABEC-5(P5)



5) Vibration and Noise level : V2, V1, Z1, Z2



6) Internal clearance codes: C0, C2, C3



7) Material: GCr 15, Stainless Steel,



8) Packing: industrial packing or individual box packing.



9) Brand: Neutral, REM, OEM



Bearing Features:



Deep Groove Ball Bearings are simple in design, non-separable and require little attention or maintenance in service, capable of operating at high speeds and are widely used radial bearings.



-6000~6020, 6200~6220, 6300~6320, 6400~6420



-6800~6810, 6900~6910



-62200~62220, 62300~62319, 63001~63010



-16001~16020, 60/22, 60/28



-87500~87510, 87605, 88505



Application of deep groove ball bearings:
Widely used in home appliances, electric tools, fitness equipment, motors, medical devices, motorbikes, textile machines, autos. Deep Groove Ball Bearing are the most common bearing type





6806 RS ceramic bearing with ZrO2 bearing  catalogue:



Type	Dimension (mm)				Basic Load Rating (N)		Limiting Speed (rpm)		Weight (Kg)
	d	D	B	r (min)	Dynamic	Static	Grease	Oil
685	5	11	3	0.15	775	317	41000	49000	0.0011
686	6	13	3.5	0.15	1080	438	37000	44000	0.0019
687	7	14	3.5	0.15	1170	511	35000	42000	0.0021
688	8	16	4	0.2	1600	714	33000	39000	0.0031
689	9	17	4	0.2	1600	734	31000	37000	0.0032
6800	10	19	5	0.3	1590	760	30000	36000	0.005
6801	12	21	5	0.3	1900	1000	25000	30000	0.006
6802	15	24	5	0.3	1960	1260	24000	29000	0.007
6803	17	26	5	0.3	2130	1360	22000	26000	0.008
6804	20	32	7	0.3	3470	2240	19000	23000	0.019
6805	25	37	7	0.3	3660	2640	16000	19000	0.022
6806	30	42	7	0.3	4020	3120	13000	16000	0.026
6807	35	47	7	0.3	4310	3610	11000	14000	0.029
6808	40	52	7	0.3	4420	3890	10000	12000	0.033
6809	45	58	7	0.3	4590	4320	9000	10000	0.040
6810	50	65	7	0.3	6600	6080	7600	9000	0.052
6811	55	72	9	0.3	8800	8500	8500	10000	0.081
6812	60	78	10	0.3	11500	10900	8000	9500	0.103



6806 RS ceramic bearing with ZrO2 bearing  picture:
