Poultry Farming Equipment Of Single Tunnel Greenhouse



    The greenhouse is suitable for planting on any scale and is suitable for the cultivation of some vegetables, flowers, fruits and poultry. Simple installation, uniform lighting and economical. It is the most widely used greenhouse in the world at this stage. He can create an environment in the greenhouse that shelters from rain, maintains temperature, controls humidity, and controls lighting.









Parameter:

Dimension	Related data
Length	10-100m
Width	6-12m
Top height	2.8-4m
Shoulder height	1-1.5m
Arch spacing	1-1.5m
Arch diameter	φ20mm,φ25mm,φ32mm,φ48mm,φ60mm
Arch thickness	1.2mm,1.5mm,1.8mm,2.0mm,2.5mm
Covering material	PE film,PC sheet,ploycarbonate sheet,PEP film
Basic equipment	Framework,door,insect net,film
Foundation	Insert the arch into the ground
Tube material	Hot dip galvanized steel tubu
Thickness of PE film	120micron 150micron 200micron



Name	Thickness	Guarantee period	Types
Plastic Film	0.06mm	14 month	PE   PO
	0.08mm	18 month
	0.10mm	2 years
	0.12mm	3 years
	0.15mm	4 years
	0.20mm	5 years





Application:

    You can install a greenhouse in a well-established location. The greenhouse can grow vegetables, fruits, flowers, etc. This greenhouse is economical and easy to install, allowing the crop to enjoy even light. If the installation location is often high winds and heavy snow, you need to choose the appropriate materials according to the actual situation.



Installation case:

     When installing, you need to install the arch and the spine first, and the parts must be tightly connected to ensure the stability of the entire frame. Then the column and the door are fixed. After the spring is assembled, the insect net and the film can be installed, and finally the film roller machine and the film roll are fixed, so that the entire installation work is completed.





Instructions for use:

    When the greenhouse is completed, daily planting of vegetables, fruits, and poultry can be carried out. If it is a greenhouse equipped with an attached system, the greenhouse administrator can adjust the lighting, temperature, humidity, etc. according to his own needs. Please strictly follow the requirements in the instruction manual. In the event of damage caused by non-human, unnatural disasters, etc., the company may provide services to replace parts or send on-site technical guidance.











Supporting system:

    The most common use in this greenhouse is the irrigation system, cooling system and ventilation system. If you have additional needs, we can also provide you with heating system,seeding nursery system, shading system, hydroponic system, lighting system, intelligent environment control system,inflator system, etc.

    The irrigation system is the most effective way of water-saving for drought and water shortage area at present.The irrigation system has two methods: drip irrigation and spray irrigation. You can choose different irrigation methods according to the characteristics of the crop and the local water source.

    The cooling system is used to lower air temperature, enhanced air circulation to cool down the indoor air. It's applicable for hot condition area.There are three ways to choose a cooling system:cooling pad,negative pressure fan,circulation fan.

    The ventilation system can be the most necessary system of a greenhouse, it can keep aircirculation in the greenhouse and will effectively prevent pests and diseases of the crops because of the anti-insect net.Manual ventilation system,this system consists of manual roller, roller pipe,roller climbing rod, 40 mesh anti-insect net, etc.Motor-driven ventilation system is consist of electric motor, transmission rolling system, roller pipe, 40 mesh anti-insect net, etc.
