MCH керамический обогреватель пеллетных

Категория: Industrial Heater >>>
Поставщик: Sinton,Electric,Co.,Ltd.

Цена:7,50 $ - 10,50 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Aug-18-2025	9.88 $*	9.45 $*
Jul-18-2025	7.17 $*	7.23 $*
Jun-18-2025	9.13 $*	9.8 $*
May-18-2025	9.78 $*	9.26 $*
Apr-18-2025	7.28 $*	7.14 $*
Mar-18-2025	9.67 $*	9.38 $*
Feb-18-2025	8.18 $*	8.81 $*
Jan-18-2025	8.72 $*	8.58 $*

Характеристики

Product Description

MCH is metal ceramic heating element. MCH refers to the design of metallic tungsten or molybdenum manganese with high melting point metal heating resistance Slurry required printing to be printed in 92 ~ 96% of alumina casting ceramic tiles, after hot-pressing laminated, then protect the atmosphere at about 1600 ℃, ceramics and metals jointly sintered and made of ceramic tiles, with corrosion resistance, high temperature resistance, long life, efficient energy saving, uniform temperature, good thermal conductivity, the speed of Heat Compensation is fast and so on, and it does not contain lead, cadmium, mercury, chromium, more, more, etc. matter, comply with environmental requirements such as EU rohs and other environmental protection requirements.

Main Specification:

* Substrate: White multi-layer alumina ceramics,.-Al2O3

* Lead: In a 0. 5mm of Nickel wire.

* Casing, tape: Teflon, high temperature resistance to high temperature

* Resistance: high temperature materials such as tungsten, etc.

* Product thickness: 0.7 ~ 2.0. Customizable

Main Features

* Small size, light weight and energy-saving

* Superior thermal properties, Rapid heating, Custom-designed temperature distribution, Excellent insulation

* High reliability: Superior voltage resistance and electrical resistance, No electric noise

Main Application:

* Wood pellet burner /Wood chips burner /Straw burner /Other biomass burner;

* 3D prinert

* Industrial drying equipment, electric Bonding liquid heater;

* Medical devices and other precise instrument.

Production Process

Packing & Delivery

Packaging
Size	123 (L) * 456 (W) * 789 (D)
Weight	1.2 T
Packaging Details	The normal package is wooden box(Size: LWH). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
