Тестер внутреннего сопротивления батареи AT5220 20 каналов 3 ом 60
- Категория: Тестеры аккумуляторной батареи >>>
- Поставщик: Xiamen,Wellzion,Electronics,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.31 $* | 0.19 $* |
| Aug-16-2025 | 0.61 $* | 0.88 $* |
| Jul-16-2025 | 0.1 $* | 0.30 $* |
| Jun-16-2025 | 0.7 $* | 0.79 $* |
| May-16-2025 | 0.98 $* | 0.99 $* |
| Apr-16-2025 | 0.22 $* | 0.5 $* |
| Mar-16-2025 | 0.62 $* | 0.99 $* |
| Feb-16-2025 | 0.96 $* | 0.1 $* |
| Jan-16-2025 | 0.83 $* | 0.93 $* |
Характеристики
AT5220,20 Channels 3Ohm 60V Battery Internal Resistance Tester
Product Overview
AT5220 is a newly designed high-precision, high-stability multi-channel battery tester. It can quickly complete sorting of 20 sets of battery voltage and internal resistance; It adopts high-performance ARM microprocessor control. True color 3.5 inch ## (LCD English display) ##, operation is more convenient. Widely used in battery manufacturers for rapid separation of contact resistance, battery voltage and battery internal resistance. A new and improved sampling circuit that can measure any kind of battery. Instrument has a professional sorting function, sorting the sound settings, adding the HANDLER interface (PLC interface) and RS-232C interface, supporting SCPI protocol and Modbus protocol (Modbus has become the national standard GB/T19582-2008) applied to automatic sorting system completes fully automated assembly line test. It can be equipped with USB interface for remote control and data acquisition and analysis, making it ideal for mass production of batteries.
Function & Benefits
- Adopt vector method and measure multi parameter silmutaneously
- Comparator(sorting) function
- Detection of damage test wire
- Compatible with SCPI
- Brand-new improved sampling circuit
Specifications
| Parameters | 20 channels AC resistance, 10 channels DC voltage |
| Accuracy | Resistance: 0.2%, Voltage: 0.01% |
| Range | Resistance:0.01mΩ~3.000Ω; Voltage:0.00001V~60.000VDC |
| Signal Source | AC 1kHz, measurement current: < 150mA |
| Range | Automatic and manual with 3 ranges |
| Speed | Fast:10CH/1s, 10CH/2s, 10CH/3s |
| Result Display | Show, ABS, deta%, θ, sorting results |
| Display Max | Resistance: 3,0000, Voltage: 60,000 |
| Adjustment | Short-circuit reset for all range |
| Comparator | NG-LO, GD-IN, NG-HI display and output. beep is adjustable |
| Trigger | Internal, manual, external and remote |
| Interface | RS-232C interface, Handler interface(PLC) |
| Power Supply | Voltage:85V AC~240V AC; Frequency:50Hz; Power:Max 15VA |
| Demension | 264mm (W)*107mm (H)*350mm (D) |
| Weight | 4kg |
