500 lph water purifier machine price ro plant 2000 lph domestic water treatment
reverse osmosis system What is RO water plant ?
RO system is raw water through precision filter, granular activated carbon filters, activated carbon
filters, compression, and then through the pump pressure, the use of reverse osmosis membrane
pore size 1/10000μm make a higher concentration of water into low concentration of water, while
the industrial pollutants, heavy metals, bacteria, viruses and other impurities in the water mixed
with a large number of full isolation, to achieve the required physical and chemical indicators for
drinking and hygiene standards, outputs to clean pure water is the best choice of body replenish
water quality. It is key equipment of pure water plant.
What's the working principle of the RO mambrane for the reverse osmosis system?
What are the RO water plantparameter?
Capacity of pure water: 250-100 000 LPH Electrical power: AC 220V 18A/ 380V 9A 50Hz High Pressure pump: CDL2S-11/2.2 KW for 500lph (1 item) Rated power: 2.0Kw/H Desalting rate:95-99% Water recovery rate: 60-75% Conductivity of raw water: ≤400μs Conductivity of pure water: ≤10μ
Technical parameter
Model
Productivity
(T/H)
Motor power
(KW)
Recovery rate
(%)
Outlet water conductivity
(μS/CM)
Raw water conductivity
(μS/CM)
CK-RO-500L
0.5
1.5
50
≤10
≤300
CK-RO-1000L
1
2.2
50
≤10
≤300
CK-RO-2000L
2
3
50-60
≤10
≤300
CK-RO-3000L
3
4.5
55-65
≤10
≤300
CK-RO-4000L
4
6.5
55-65
≤10
≤300
CK-RO-5000L
5
8
60-70
≤10
≤300
CK-RO-10000L
10
15
60-70
≤10
≤300
CK-RO-20000L
20
22
65-75
≤10
≤300
CK-RO-30000L
30
26
70-75
≤10
≤300
CK-RO-50000L
50
55
70-75
≤10
≤300
Detail Images
Function of each part of water treatment plant 1.feed water pump pump-- provide the pressure to quartz sand filter/active carbon filter 2.Multi-medium filter-- get rid of turbidity, suspended matter, organic matter, colloid, ect. 3.Active Carbon filter--Remove the color, free chloride, organic matter, harmful matter, ect. 4.Softener--exchange "ions" of calcium and magnesium with the most common and easiest method. 5.Security filter--prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um 6.High pressure pump-- Provide the high pressure to RO membrane 7.RO system-- main part of the plant. The RO membrane's desalting rate can reach 99%, removing over 99% ions 8.UV sterilizer or ozone generator--- kill bacteria
Flow Charts of RO machine
We are using high quality accessories, parts and equipments
Feature and advantages:
1.System can produce water continuously and high degree automation.
2.No need chemical to regenerate, easy operation and maintenance.
3.Core components of ro system are imported USA membranes.
4.Automatic switch on when low water level, and switch off when high water level
7.Product water conductivity meter can monitor water quality online continuously.
8.Low operation cost and long life span
Application:
1). Electronic industry: Pre-filter for ultra pure water, chemical products and pure water
2). Food and beverage industry: filter for mineral water, wines and fruit juice 3). Medicine industry: filter for drug liquid, gases 4). Chemical industry: filter for organic solvent 5). Petroleum industry: filter for oil-field flooding
Product line
Company Information
Packaging & Shipping
Packaging Details: 1.All equipment are packed with wooden/carton box or wrapping film. 2.All parts are fastened in container, guarantee that no damage while shipping. Delivery Detail: 7-10 work days after receiving 30% prepayment.
Our customers
We attend professional water treatment fair to promote our products. A great many of customers would come to our booth, show interest in our products and are willing to try our products. Trial order to test quality is warmly welcomed too!
7/24 HOURS TECHNICAL SUPPORT
The customer service hotline is open 7/24 hours to provide timely technical support, question answering and urgent problem handling.
NETWORK SUPPORT
We provide various types technical support by providing e-mails, whatsapp, wechat, teamviewer etc. online communication
tools.
FAQ
Q: Are you trading company or manufacturer ? A: Yes, we are a manufacture with designing, manufacturing, marketing and exporting. Q: What's the information you need to know before order? A: what's your raw water ? B: what's the capacity per hour of the equipment ? C: What’s the application of purifier water ? Q:Which machine should I choose? A:It depends on your raw water quality ,pure water requirement and the water production you need Q: What is your terms of payment ? A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 40% T/T in advance ,60% TTbalance before shipment. Q: How long is your delivery time? A: Generally it is 15-30 days, Depends on your project. Q:How can you control the quality and delivery? A:All our machines will be tested before packaging. wooden packing is strong and safety for long delivery. Q:What’s your warranty? A:Our warranty is 1 year. But normally, our machine can work 5 years before repair.
