Чип 0805 1 чип серии высокой яркости T0.8mm типа SMD LED
US $0.02-$0.05
Высокое качество Epileds Chip фиолетовый синий цвет 420 нм 425nm 430nm 435nm 440nm 1 Вт 2 3 высокой мощности светодиод технический
- Категория: SMD LED >>>
- Поставщик: Shenzhen,Yingfeng,Opto-Electronic,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.27 $* | 0.50 $* |
| Aug-15-2025 | 0.66 $* | 0.9 $* |
| Jul-15-2025 | 0.21 $* | 0.78 $* |
| Jun-15-2025 | 0.61 $* | 0.60 $* |
| May-15-2025 | 0.6 $* | 0.92 $* |
| Apr-15-2025 | 0.27 $* | 0.44 $* |
| Mar-15-2025 | 0.96 $* | 0.99 $* |
| Feb-15-2025 | 0.58 $* | 0.95 $* |
| Jan-15-2025 | 0.54 $* | 0.40 $* |
Характеристики
| Order Code | Voltage (V) | Peak Wavelength (nm) | Radiant Power (mW) | Radiant Intensity (mW/sr) | Current (mA) | Half Width (nm) | Angle (0) | Electric power (W) |
| HYR35X43B365KN-D1 | 3.5-4.0 | 365-370 | 1500-2000 | 375 | 700 | 9 | 120 | 3 |
| HYR35X43B380KN-D1 | 3.2-3.6 | 380-390 | 1800-2300 | 455 | 700 | 10 | 120 | 3 |
| HYR35X43B395KN-D1 | 3.0-3.4 | 395-400 | 1700-1900 | 438 | 700 | 15 | 120 | 3 |
| HYQ35G45N400KN-D1 | 3.0-3.4 | 400-410 | 1300-1500 | 355 | 700 | 17 | 120 | 3 |
| HYQ35G45N410KN-D1 | 3.0-3.4 | 410-420 | 900-1100 | 346 | 700 | 17 | 120 | 3 |
| HYQ35G45N420KN-D1 | 3.0-3.4 | 420-430 | 900-1100 | 324 | 700 | 16 | 120 | 3 |
| HYQ35G45N430KN-D1 | 3.0-3.4 | 430-440 | 700-800 | 335 | 700 | 19 | 120 | 3 |
| HYR35G30N365KN-D1 | 3.5-4.0 | 365-370 | 1000-1200 | 238 | 500 | 11 | 120 | 2 |
| HYQ35G40P395KO-D1 | 3.2-3.4 | 395-397 | 600-800 | 187 | 500 | 20 | 120 | 3 |
| HYR35X43B365KN-X1 | 3.5-4.0 | 365-370 | 1500-2000 | 375 | 700 | 9 | 60 | 3 |
| HYR35X43B380KN-X1 | 3.2-3.6 | 380-390 | 1800-2300 | 455 | 700 | 10 | 60 | 3 |
| HYR35X43B395KN-X1 | 3.0-3.4 | 395-400 | 1700-1900 | 438 | 700 | 15 | 60 | 3 |
| HYQ35G45N400KN-X1 | 3.0-3.4 | 400-410 | 1300-1500 | 355 | 700 | 17 | 60 | 3 |
| HYQ35G45N410KN-X1 | 3.0-3.4 | 410-420 | 900-1100 | 346 | 700 | 17 | 60 | 3 |
| HYQ35G45N420KN-X1 | 3.0-3.4 | 420-430 | 900-1100 | 324 | 700 | 16 | 60 | 3 |
| HYQ35G45N430KN-X1 | 3.0-3.4 | 430-440 | 700-800 | 335 | 700 | 19 | 60 | 3 |
| HYR35X43B365KN-S1 | 3.5-4.0 | 365-370 | 1800-2300 | 1270 | 700 | 9 | 45 | 3 |
| HYR35X43B380KN-S1 | 3.0-3.4 | 380-385 | 1800-2300 | 1230 | 700 | 10 | 45 | 3 |
| HYR35X43B400KN-S1 | 3.0-3.6 | 400-405 | 1700-2000 | 1150 | 700 | 13 | 45 | 3 |
Warm Tip:The above parameters are for reference. Wavelength Angle, PCB can be customized according to requirements
