Вилочный погрузчик на 2 тонны 3 5 с дизельным двигателем сертификат

Описание и отзывы

Трекер стоимости

Характеристики

Characteristics	Fuel type			Diesel
	Load capacity		kg	3000
	Load center		mm	500
	Lift height		mm	3000
	Full free lift height		mm	135
	Fork dimension		mm	1070×125×45
	Mast tilting angle		Deg.	6/12
	Min. turning radius		mm	2470
	Min. width of right angle stacking channel		mm	4280
	Min. width of right angle channel		mm	2120
	Groud clearance		mm	120
	Overhead guard height		mm	2120
	Front overhang		mm	498
Performance	Max. travel speed		km/h	19
	Max. lift speed		mm/s	460
	Max. traction power		KN	20
	Max. gradeability		%	20
Dimensions	Total length	With fork	mm	3805
	Total length	Without fork	mm	2735
	Total width		mm	1230
	Mast extended height		mm	4265
	Mast lowered height		mm	2040
Chassis	Tyres	Front		28x9-15-12PR
		Rear		6.50-10-10PR
	Wheelbase		mm	1700
	Tread	Front/Rear	mm	1000/970
	Service weight		Kg	4300
Drive	Battery		V/Ah	12/100
	Motor	Model		XINCHAI 490
		Rated output	kw/r.p.m	34.3/2500
		Rated torque	N.m/r.p.m	137.7/1800
		Cylinders		4
		Displacement	L	2.37
	Fuel tank capacity		L	70
	Transmission
	Operating pressure		Mpa	17.5





Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.

Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.

Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and
the courier cost.

Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
