Двойные прозрачные поликарбонатные полые листы с УФ-защитой 6 мм сотовые кровельные

Описание и отзывы

Трекер стоимости

Характеристики

UV Protection 6Mm Twin wall Clear Polycarbonate Hollow  Sheet Honeycomb Roofing Sheets



Production Specification:

Polycarboante Hollow Sheet

Walls	Grade Name	Thickness	Weight (kg/sqm)	Rib Distance (mm)	U-value (W/sqm·k)	UV Side	LT(%) Clear	LT(%) Opal White
	GREAD A	4	0.9	5.5	3.8	One Side	82	30
2-wall R-strusture	GREAD A	5	1.1		3.7		81	30
	GREAD A	6	1.3		3.5		80	25
	GREAD A	8	1.5	10	3.3		80	30
	GREAD A	10	1.7		2.9		78	30

	GREAD A	6	1.6		3.4		80
	GREAD A	8	1.8		3.2		78
triple wall	GREAD A	10	2.0		2.8		76
four wall	GREAD A	12	2.2		2.7		74
honeycomb	GREAD A	14	2.4		2.6		72
	GREAD A	16	2.6		2.5		70
	GREAD A	18	2.8		2.4		68
	GREAD A	20	3.0		2.0		66



Property	Method	Condition	Units	Value
Density		D-1505	g/cm3	1.2
Heat deflection temperature	GB/T1634	D-648	℃	135
Combustion Performance	GB/T8624	UL94	Grade	B1/V2
Service Temperature-Long Term			℃	-50 to±100
Coefficient of Liner Thermal Expansion	GB/T1036	D-696	Mm/m℃	0.065
Tensile Strength at yield	GB/T1040	D-638	Mpa	62
Elongation at Break	GB/T1040	D-639	%	>80
Impact Falling Dart	GB/T14153A	ISO 6603/1	times	1/10
Practical Thermal Expansion/Contraction	GB/T2680		%	0



Related  Polycarboante Hollow Sheet:



























Raw Mateiral:



Our Company:





 Production Line:





 Warehouse:



Canton Fair:





 Successful Project:

 Applications of Foshan SHANTEL Bayer Polycarbonate Sheeting
   1) Roofing for swimming pool, shopping malls, commercial streets.
   2) Sunshade for stadiums and bus stops, gazebo, open-air carport.
   3) Lighting canopy for corridors,passages and subway entries.
   4) Flashing for bank ATMs, telephone box, gateways, garages.
   5) Sound and heat insulation wall for expressways and houses.
   6) Heat preservation material for agricultural greenhouse, flower greenhouse.
   7) Soundproof material for partitions.
   8) Unbreakable material for glazing windows, roof glazing.







FAQ

Q1: Are you trading company or manufacturer ?
A: We are factory and specialize in polycarbonate solid sheet,pc hollow sheet ,pc corrugated sheet ,pc awnings etc.

Q2: How long is your delivery time?
A: Generally it take 7-10 days.

Q3: Do you provide samples ? is it free or extra ?
A: Yes, free sample are available,but delivery cost is pay by customer.

Q4: What is your terms of payment ?
A:  30% deposit T/T in advance ,70% balance before shippment.
