Характеристики


sand washing machinesand washing machinesand washing machine

sand washing machine

sand washing machine introduction

sand washing machine  is used to removing the dust in ore and grading ore for the metallurgic, construction material and hydro power industries. It is suitable for the washing work of the fine grain and coarse granularity material.
sand washing machine is suitable for fine grain and coarse granularity material the washing work,especially suitable for washing the ore for building and ore for road. sand washing machine has the characteristics of rational construction, easy maintenance, big capacity, low power consumption and high washing cleanliness. The novel leak proof structure,fully enclosed oil bath type transmission device and adjustable overflow weir board guarantee the high performance of screw ore washer.

sand washing machine application

1. Separation of fine particles and liquid from coarse particles
2. Separation of light particles from heavy particles
3. Separation of the particles into a number of products graded according to size
4. Separation of liquid from solid particles

working principle of sand washing machine

The sand washing machine adopts inclination of 15°,under the water tub, three weir plates form the sediment pool, the screw head is immersed in this pool, the screw is driven by electric motor through reducer rotating continuously, the fresh water is feeding from porous plate at bottom of sediment pool. The sand washing machine is a kind of sand washing machine, appliance by water fit with the sand maker. The sand washer can wash away micro amount of stone powder and impurity from the mixed sand made by the sand maker to improve the quality of the sand. The sand washer impelled by generator and redactor drives the impeller to rotate in circles continuously in the water tank and then to make the sandstones and slag particles mixed, inverted and washed in the tank and discharged after dehydration of the materials in the impeller.


sand washing machinesand washing machine

Screw sand washer Specifications:



ModelScrew Diameter (mm)Tank Length (mm)Screw QuantityMax Feeding (mm)Capacity (t/h)REV (r/min)Power (kw)Motor ModelWater Consumption (t/h)Machine Size (mm)
LSX92092075851≤10100216-11Y160L-6/1110-808420×2180×3960
2LSX92092075802≤10200216-11×2Y160L-6/1120-1608420×3970×3960
LSX1120112097501≤10175176-18.5Y200L1-6/18.520-15010770×3950×4860
2LSX1120112097502≤10350176-18.5×2Y200L1-6/18.540-30010770×5260×4860





Packaging & Shipping

sand washing machine



Company Information

ABOUT US



Shanghai Zenith Minerals Sales CO., LTD is one high-tech enterprise, which involves R&D, production, sales and service as well. In the past 20 years, we devote to producing mining equipments, sand making machines and industrial grinding mills, offering expressway, rail way and water conservancy projects the solution of making high grade sand and matched equipments. sand washing machine

The head office of Zenith is in Shanghai- the international financial centre. Here we have modern production base of 2.3 million square meters, professional R&D institution and technology team, which make us world-class company. Here all Zenith machines are designed produced, assembled and texted according to the ISO9001:2008.

Till now, our products are sold to 130 countries, being the popular equipments in global crushing and grinding industry. With the development of our Zenith, we would like to help more and more customers start their business in mining and construction industries, offer them the good solution, much more advanced machinery and better service.



Certifications



sand washing machine



Our Services

Pre-sales Service:
The wide product range enables us to provide our customers with stand-alone machines or complete processing plants. Based on our customers’ request and budget, our experts make efficient, reliable solutions. Following customers’ order we produce strictly, what’s more, before placing the order every customer has the chance to visit zenith working machines or complete plant in the site.


To ease the trip for every visitor to China, in particular the first-time visitor, we provide FOR FREE all relevant visitor-friendly services including invitation letter preparation, hotel reservation, airport pick-up, incity transportation, and sightseeing guide, etc.

sand washing machine


After-sales Service:


Experienced technicians guidance is available on the phone, and on the internet. One or more engineers will be dispatched to the quarry site to help install the customers’ plants. Necessary training about machine daily maintenance to local workers is provided also.


After-Sales department is made of well-trained employees and installation engineers, the installation engineers are special and professional members of Zenith, they are now strategically located home and abroad, working for our customers.



FAQ

1.How is the quality of your products?
Our products are manufactured strictly according to national and international standard, and we take a test on every grinder before delivery.


2.Guaranteed:
If products’quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.


3.How about price?
Yes, we are factory and be able to give you the lowest price than market one, and we have a policy that “ for saving time and absolutely honest business attitude,we quote as low as possible for any customer, and discount can be given according to quantity”.


4.Service and Payment Terms?
A. We usually accept T/T, L/C;
B. T/T: 30% in advance as down payment, the balance before delivery;
C. We take pictures of finished products before delivery.
