240 Вт Светодиодный прожектор заливающего света для наружного теннисного
- Категория: Высокомачтовые светильники >>>
- Поставщик: Luohe,Hilight,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 157.22 $* | 165.32 $* |
| Aug-16-2025 | 156.50 $* | 164.81 $* |
| Jul-16-2025 | 131.61 $* | 138.28 $* |
| Jun-16-2025 | 153.31 $* | 161.86 $* |
| May-16-2025 | 133.48 $* | 140.34 $* |
| Apr-16-2025 | 150.5 $* | 158.82 $* |
| Mar-16-2025 | 149.73 $* | 156.7 $* |
| Feb-16-2025 | 148.17 $* | 155.20 $* |
| Jan-16-2025 | 147.19 $* | 154.28 $* |
Характеристики
Technical Data
Item name | 200W LED high mast flood lights |
Power | 200W |
Light Source | SMD5050 |
LED Quantity | 98 pcs |
LED Driver | MEANWELL Driver |
Input Voltage | AC 85~305V 50/60Hz |
Color Temperature | 2700-6500K |
Light effect | 140LM/W |
Lumen | 28,000LM |
CRI | Ra.≥80 |
PF | 0.95 |
IP | 65 |
Viewing angle | 10° 25° 60° |
Materials | Aluminum |
Operating Temp. | -40ºC ~ +60ºC |
Applications | tunnel,park,bridge,plant, workshop,stadium, etc. |
Qty / CTN | 1PC |
N.W. | 9.2KG/PC |
G.W. | 10.2KG / PC |
Lamp dimensions | 315 x 420 x 155mm |
Carton size | 46 x 51 x 25cm |
Lifetime | 50,000 hours |
Quality warranty | 5 years |
Certificates | CE,ROHS, EMC, LVD, ISO9001 |
Product Features
200W/300W/400W/500W/600W/700W/900W/1000W/1200W available.
* More suitable for stadium.
* IP65 waterproof design protect the lamp better.
* Heat sink independent design makes ventilation.
* Not only for stadium lighting, but also can use as high-pole lamp.
* Lighter weight, smaller volume save freight cost. More safty during using.
* Lumileds 5050 LED has better heat dissipation, provide 140LM/W.
* MEANWELL driver with 5 years warranty.
* 10°/25°/60°beam angle for option.
* IP65 waterproof design protect the lamp better.
* Heat sink independent design makes ventilation.
* Not only for stadium lighting, but also can use as high-pole lamp.
* Lighter weight, smaller volume save freight cost. More safty during using.
* Lumileds 5050 LED has better heat dissipation, provide 140LM/W.
* MEANWELL driver with 5 years warranty.
* 10°/25°/60°beam angle for option.
Product Detail
With two ways of installation, suitable for varies application, black color housing and beauty designed.
There are 10°,25°, 60° beam angle options for the Lens.
Scientifically-designed heat dissipater with much better cooling effect.
High luminous efficiency, Whole lamp output light efficiency >140LM/W.
High quality power supply, input voltage AC85-305V.
The power efficiency is more than 90%, power factor greater than 0.95.
The adjustable bracket,180°adjustable,adjust as you want.
Fin style heat sink design makes the heat dissipation perfect and extend lamp's lifespan,the lamp's lifetime are 50,000 hours.
Applications
It can be widely used in stadium,tunnel,square,garden,lawn,playground,tennis,golf course,bus station,airport,sculpture,architecture,street,parking lot etc.
Installation Notes
1. Non-specialist electricians please do not repair or modify this product without authorization;
2. Please turn off the power before installation;
3. Before installation, please check whether the voltage marked on the lamp is consistent with the input voltage to be connected;
4. In order to ensure the service life of the product, please do not use it in a place with strong acid mist;
5. Pay attention to shock protection during installation and transportation;
6. Before installation, ensure that the installation position can withstand 10 times the weight of the product, and install it in a flat place without vibration, no swing, no fire hazard;
7. If the lamp fails, please place the lamp in one place and send it back to the company for inspection and repair.
8. If the lamp body or wire is damaged, please stop using it immediately.
Contact us
Certifications
About us
We have 6 production lines at production department, including assembling, inspection and aging test lines.
Production ability: 3-5 days for 100pcs LED high mast flood light , and 10-15 working days for 2000pcs LED high mast flood light at common requirements.
Each Lamp must pass 24 hours aging test and high voltage (3KV) surge test before we make packing and make delivery.
Our Services:
1. For all your inquires about us or our products, we will reply you in detail within 24 hours;
2. Excellent design team with designers of more than 12 years experience, can offer professional advice for practical application;
3. 5000,000 pcs light source annual production capacity, the products export to EU market, American market, Russia, Kazakhstan, Australia, South Africa, Zimbabwe, Vietnam, etc;
4. Good OEM & ODM business ability, 6 production lines meet your shipping requirement;
5. Export port Shenzhen, Hongkong or Shanghai;
6. Discount available for bulk order;
7. High quality component and material, Filips, Bridgelux, 3030SMD, 5050SMD, Epistar LED chips, MW / Sosen / HT/ TUV SAA CE listed driver etc, depend on your needs.
Payment Terms:
TT Bank Transfer, support 30% deposit and 70% before delivery;
PayPal, western union, Alipay etc.
NO O/A.
Delivery time:
Samples and less than 100pcs in 3-5 working days;
500pcs in 7-8 working days;
2000pcs in 15 working days.
About Shipping:
Samples sent by DHL, TNT, FedEX, UPS, SF Express, Aramex etc. Door to door, you may pay customs tax depends on your customs policy.
By air or by sea for bulky orders available.
FAQ:
1. Are you factory supplier?
Yes, we are manufacturer of LED lamps since 2008 and we have our own factory, supply duable super quality items and reliable after-sale service.
2. Do you supply OEM or ODM?
Yes, we can supply OEM and ODM serice with favorable price and we have our own mould workshop, your brand and logo can be printed on the items.
3. How long will it spend for our orders to be sent out?
It takes 3-5 days for samples at common requirements, and 10-15 days for big order such as 2000pcs led high bay flood lights.
4. What about your after-sales servie and warranty policy?
We offer 5 years warranty for this led high bay flood lights, by supplying you the lamp parts or new replacements for free during the warranty period for any non-human defective lamps.
