Superlive plus mobile app novatek cctv dvr,16ch 5MP lite/1080P AHD/CVI/TVI/CVBS/IP 5 in 1 hd xvr


Products Description






Features:
>.16 CH TVI/AHD/CVI 5MP/4MP/1080P/720P/WD1 video input
>.16 CH DVRs support 8CH 5MP/4MP/3MP /1080P/960P/720P IP video input
>.Adopt standard H.265 high profile compression format to get high-quality video at much lower bit rate
>.Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse
>.Multi-mode recording: manual / timed / motion /AI recording ,Playback : 16CH simultaneously playback
>.Search: time slice, time, event, tag search
>.Express and flexible backup via USB, network and so on
>.Pentaplex: preview, record, playback, backup and remote access
>.DHCP, DDNS, PPPoE network protocol
>.Remote control via Web or CMS : preview, playback, backup, PTZ and configuration
>.Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
>.Authorization management, log review and device status review
>.Support 1080P output, true high resolution display
>.Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
>.Support NAT function and QR Code scanning by mobile phones
>.Powerful mobile surveillance by smart phones with iOS and Andriod OS


Specification


Model
XVR5116-V3
System
OS
Embedded Linux
Video
Analog Video Input
BNC × 16
BNC interface (1.0Vp-p; 75Ω)
TVI/ AHD/CVI : 5MP/ 4MP/ 1080P/ 720P/ WD1
IP Video Input
8CH
Up to 5MP@30fps
Total Input
24CH
Output
HDMI × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
BNC × 1 : CVBS ( used as the main or spot output )
Compression
H.264/H.265
Multi-screen Display
1 /4/6/8/9/13/16/25
Audio
Input
RCA × 1
Output
RCA × 1 (linear, 600Ω)
Two-way audio
Take up channel one audio input
Compression
G.711(U/A)
Record
Resolution
5MP Lite/ 4MP Lite/ 1080P/ 1080P Lite/ 720P/ WD1
Frame Rate
Analog Channel: 5MP Lite :10fps;
4MP Lite/1080P : 12fps (PAL)/15fps (NTSC);
1080P Lite/720P/WD1 : 25fps (PAL)/30fps (NTSC)
IP Channel: 25fps (PAL)/30fps (NTSC)
Bit Rate
32Kbps ~ 5Mbps
Mode
Manual, timer, motion, smart event
Playback
Playback
16CH
Search
Time slice / time / event / tag search
Smart Search
Highlight colors to display the camera record in a certain period of time, different colors refer to different record events
Function
Play, pause, FF, FB, digital zoom, etc.
Alarm
Mode
Manual, motion, exception, smart event
Input
No
Output
No
Network
Interface
RJ 45 100Mbps × 1
Protocol
TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, HTTP, HTTPs, NTP, SMTP
Incoming Bandwidth
32Mbps
Outgoing Bandwidth
80Mbps
Client Connection
Max. 10 users access
Mobile Device
OS
iOS, Andriod
Storage
HDD
SATA × 1, up to 10TB
Backup
Local Backup
U disk, USB mobile HDD
Network Backup
Yes
Port
RS 485
RS 485 × 1 (half-duplex)
USB
USB 2.0 × 2 ( in the rear panel )
Remote Controller
Optional
Others
Power Supply
DC12V / 3A
Consumption
≤10W(without HDD )
Dimensions(mm)
255× 234× 42 ( W × D × H )
Working Environment
-10~50°C, 10%~90% (humidity)
Certificate
CE, FCC
Environmental Protection
Comply with Directive EU RoHS, WEEE, REACH
