Грузовик с воздушной платформой для

Vehicle Parameters

General

Vehicle Model

YZR5040JGK12Q

Vehicle Brand

XDR

Chassis Brand

Qing ling

Overall Dimension(mm)

5998×2000×2960

GVW/Curb Weight(kg)

4495 /4170

Chassis Parameters

Cab

Cab Seat

2

Air Conditioner

Optional

Engine

Fuel Type

diesel

Engie Model

4KH1CN5LS

Engine Brand

Qing ling

Power

72hp

Displacement(cc)

2999

Emmission Standard

Euro3

Chassis

Drive Type

4*2

Transmission

5 speed, Manual

Wheelbase(mm)

3360

Tyre Specification

6.50-16

Tyre No.(pcs)

6+1

Max Speed(km/h)

99

Paint

Yellow

Aerial platform structure parameters

working height(m)

12

Maximum working radius(m)

6

Arm Material

carbon steel Q345

Arm  Thickness

Working height at Max.working radius(m)

6.4

Working radius at Max.working height(m)

Outrigger distance(mm)

2880*3560

Platform average rise speed(m/s)

≤0.4

Platform average fall speed(m/s)

≤0.4

Rotation speed (1r/min)

1

Arm structure type

Three section

Outrigger stretch time (s)

40

Rotation

360°continuous rotary

Outrigger

H type,independently

Remarks

1. truck chassis brand is selectable  2.The outrigger operation box is equipped with a lighting device to facilitate work at night and configure the vehicle's bidirectional level to ensure the vehicle's level and ensure safety.3.The boom rotation is designed as a one-piece swivel to avoid assembly gaps during reassembly in production, and increases the space of the platform.4.Front and rear H-shaped legs, good stability, can be operated simultaneously or individually, standard washing boxes for all models 5.Upper arm limit device, when the upper arm exceeds the safety angle, the boom will be in a self-locking state to ensure the safety of the operator 6.Up and down steps are equipped on the side(aluminum alloy platform optional )7.The thickened cylinder seat and the boom cylinder block are all specially thickened to ensure the stability of the boom 8.Sectional coating to ensure the paint quality of the vehicle 9.All cutting parts are CNC laser cutting
