Гидравлический сверлильный станок для скважин сверлильные машины на
- Категория: Горное оборудование >>>
- Поставщик: Jining,Luheng,Machinery,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 4403.95 $* | 4623.8 $* |
| Aug-20-2025 | 4366.99 $* | 4584.94 $* |
| Jul-20-2025 | 3663.18 $* | 3846.81 $* |
| Jun-20-2025 | 4292.91 $* | 4507.82 $* |
| May-20-2025 | 3737.15 $* | 3924.65 $* |
| Apr-20-2025 | 4218.96 $* | 4429.20 $* |
| Mar-20-2025 | 4181.0 $* | 4390.31 $* |
| Feb-20-2025 | 4144.46 $* | 4351.77 $* |
| Jan-20-2025 | 4107.83 $* | 4312.51 $* |
Характеристики
Product Description
hydraulic drilling machine water well bore hole drilling machines for sale
1.HW-160 water well drilling rig Features
a. the machine is equipped with crawler chassis device,easy to move with fast speed.
b. hydraulic oil pressure feed device,improve drilling defficiency.
c. pressure gauge display the condition of the bottom of the drill hole.
d. drill mast controlled by hydraulic cylinder,improve the efficiency diesel engine adopt the electric starter,to reduce the labor itensity.
a. the machine is equipped with crawler chassis device,easy to move with fast speed.
b. hydraulic oil pressure feed device,improve drilling defficiency.
c. pressure gauge display the condition of the bottom of the drill hole.
d. drill mast controlled by hydraulic cylinder,improve the efficiency diesel engine adopt the electric starter,to reduce the labor itensity.
2. HW-160 Water Well Drilling Rig Applications
HW-160 drilling rig is mainly used for geological general investigation and exploration,road and tall buliding foundation
exploration,kinds of hole in concrete structure,river levees,subgrade grouting hole,drilling and driect grouting,civil wellsand
earth temperature central air-conditioner,etc.
HW-160 drilling rig is mainly used for geological general investigation and exploration,road and tall buliding foundation
exploration,kinds of hole in concrete structure,river levees,subgrade grouting hole,drilling and driect grouting,civil wellsand
earth temperature central air-conditioner,etc.
Specification
SPECIFICATIONS FOR DRILLING RIG Model HW160 | ||||||
HW160 drilling rig | Drilling depth | m | 160 | |||
Open hole dia soil/rock | mm | 500/220 | ||||
End hole dia | mm | 75 | ||||
Drill rod dia | mm | 42/50 | ||||
Drill angle | ° | 90-75 | ||||
Engine power | kw | 13.2 | ||||
whole machine weight without engine | kg | 600/740 | ||||
Overall machine size | mm | 2400*800*1300 | ||||
Spindle | Speed | r/min | 142/285/570 | |||
Stroke | mm | 450 | ||||
Winch | single rope lift force | kg | 2000 | |||
single rope lift speed | m/s | 0.41-1.64 | ||||
rope diameter | mm | 9.3 | ||||
drill mast | rated load | ton | 18 | |||
effective height | mm | 6.5 | ||||
mud pump | flow | L/min | 95 | |||
max pressure | Mpa | 1.2 | ||||
work pressure | Mpa | 0.7 | ||||
inlet pipe dia | mm | 30 | ||||
outlet pipe dia | mm | 20mm | ||||
Customer feedback
Water well drilling rig project in Malaysia with mud pump
tricycle mounted water well drilling equipment project in Thailand for hard soil geology
Crawler chassis hydraulic drill tower with winch , drilling water well project in China Fujian for soil geology
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
hydraulic drilling machine water well bore hole drilling machines for sale
Company Profie
Jining Luheng Machinery Equipment Co., Ltd. as one of the seven branches of head office Shandong Hengwang Group Co., Ltd. is a professional company engaged in research , development, production, sales, application and service of rock drilling rig machines and pile driver machines. With more than 400 workers and 25 senior engineers, high quality products and best after sales service can both be guaranteed. Hengwang is eyeing the global market with world class products and services and is working hard and moving forward to help the rise of China national machinery and equipment manufacture industry.
FAQ
Q1.What is the main function of our crawler environmental sampling soil core drilling rig?
Ans.: It has different models used for all kinds of working site.
Q2. What is your terms of payment?
Ans.: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
Ans.: EXW, FOB, CFR, CIF.
Q4. How about your delivery time?
Ans.: Generally, it will take 7 -10 working days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. What is the warranty of our machine?
Ans.:Our main machine enjoys a 1 year warranty(except for the hammer), during this time all accessories broken can be changed for a new one.And we provide videos for machine install and operation.
Q6. What is your terms of packing?
Ans.: Generally, we use standard exported wooden case for LCL goods, and fixed well for FCL goods.
Q7. Do you test all your goods before delivery?
Ans.: Yes, we have 100% test before delivery.And we will attach our inspect report for every machine.
Q8.Do you Preferred provide wear parts for transacted clients?
Ans.: Yes, we have recor d s for your clients, and will prefer provid ing accessories to clients.
Q9: How do you make our business long-term and good relationship?
Ans.: 1. We keep good quality and competitive price to ensure our customers benefits; 2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
Q10.Do you have any certificates for your machine?
Ans.: All of our produ c ts coming with the certificates of CE, ISO9001.
Ans.: It has different models used for all kinds of working site.
Q2. What is your terms of payment?
Ans.: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
Ans.: EXW, FOB, CFR, CIF.
Q4. How about your delivery time?
Ans.: Generally, it will take 7 -10 working days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. What is the warranty of our machine?
Ans.:Our main machine enjoys a 1 year warranty(except for the hammer), during this time all accessories broken can be changed for a new one.And we provide videos for machine install and operation.
Q6. What is your terms of packing?
Ans.: Generally, we use standard exported wooden case for LCL goods, and fixed well for FCL goods.
Q7. Do you test all your goods before delivery?
Ans.: Yes, we have 100% test before delivery.And we will attach our inspect report for every machine.
Q8.Do you Preferred provide wear parts for transacted clients?
Ans.: Yes, we have recor d s for your clients, and will prefer provid ing accessories to clients.
Q9: How do you make our business long-term and good relationship?
Ans.: 1. We keep good quality and competitive price to ensure our customers benefits; 2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
Q10.Do you have any certificates for your machine?
Ans.: All of our produ c ts coming with the certificates of CE, ISO9001.
