VINSON Harman пеллетная печь 336 Вт/240 в 15 плавник нагревательный
VINSON Harman пеллетная печь 336 Вт/240 в 15 плавник нагревательный
VINSON Harman пеллетная печь 336 Вт/240 в 15 плавник нагревательный
VINSON Harman пеллетная печь 336 Вт/240 в 15 плавник нагревательный
VINSON Harman пеллетная печь 336 Вт/240 в 15 плавник нагревательный
VINSON Harman пеллетная печь 336 Вт/240 в 15 плавник нагревательный

VINSON Harman пеллетная печь 336 Вт/240 в 15 плавник нагревательный


Поделиться:


Цена:5,20 $ - 6,50 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Aug-19-2025 6.81 $* 6.43 $*
Jul-19-2025 5.92 $* 5.6 $*
Jun-19-2025 6.70 $* 6.43 $*
May-19-2025 6.56 $* 6.0 $*
Apr-19-2025 5.42 $* 5.4 $*
Mar-19-2025 6.84 $* 6.92 $*
Feb-19-2025 6.58 $* 6.77 $*
Jan-19-2025 6.50 $* 6.54 $*

Характеристики


Product Description

Cartridge heaters are most frequently used for heating metal parts by insertion into drilled holes. For easy installation, the heaters are made slightly undersize relative to their nominal diameter.
Cartridge heaters can be easily specifed to meet the demands of special applications. Simply select from a variety of standard options and features to customize the heater to your specifc needs. For customized engineering or alternative options, contact vinson's sales representative for fast turnaround on your specifcations.

* 3/8" diameter x 3 1/4" length
* 240v/336w
* fin: 15 pcs, length: 1"
* material: stainless steel 304
* with female connector


Cartridge heaters are an extraordinarily versatile and durable product that is used to heat a myriad of different processes from heavy industrial – plastics and packaging applications to critical care medical devices and analytical test instruments to being used on aircrafts, railcars and trucks. Cartridge heaters are capable of operating at temperatures of up to 750℃ and achieving watt densities of up to 30 watts per square centimeter. Available from stock or custom manufactured to your individual application need, they are available in many different imperial and metric diameters and lengths with many different style terminations, wattage and voltage ratings.

Cartridge heaters are an excellent choice to use as a conductive source for heating solid metal plates, blocks and dies or as a convective heat source for use in a variety of liquids and gases. Cartridge heaters can be used in a vacuum atmosphere with proper design guidelines.

Typical Applications.

• Semiconductor chamber heating
• Semiconductor wire and die bonding
• Freeze protection and deicing of equipment in cold
climates or applications
• Humidity control
• Patient comfort heating used in medical devices
• Mold die and platen heating
• Seal bars used in packaging equipment
• Test sample heating in gas chromatography equipment

Technical Data:.

Tube diameter: customized,Min dia.2.8mm
Tube Material:SS304;SS316,SS321,NICOLOY800 etc.
Insulation Material:High-purity Mgo
Reisistance wire element:Ni-Cr or FeCr
Wattage density: high/middle/low(5-25w/cm2)
Lead Connection Option: Crimped or Swaged leads
Lead wire type: 10" Standard(Teflon/silicone high temperature frberglass)

\t
Dia*L (mm)
\t
Power (low density)
\t
Power (high density)
\t
Dia*L (mm)
\t
Power (low density)
\t
Power (high density)
\t
6-60
\t
60W
\t
120W
\t
14-100
\t
200W
\t
450W
\t
6-80
\t
100w
\t
200W
\t
14-120
\t
250W
\t
520W
\t
6-200
\t
190W
\t
350W
\t
14-150
\t
330W
\t
650W
\t
8-50
\t
65W
\t
120W
\t
14-200
\t
400W
\t
880W
\t
8-100
\t
125W
\t
250W
\t
14-250
\t
550W
\t
1000W
\t
8-150
\t
200W
\t
350W
\t
14-300
\t
650W
\t
1300W
\t
8-200
\t
250W
\t
500W
\t
16-100
\t
250W
\t
500W
\t
10-60
\t
100W
\t
200W
\t
16-120
\t
300W
\t
600W
\t
10-80
\t
125W
\t
250W
\t
16-150
\t
350W
\t
750W
\t
10-120
\t
200W
\t
375W
\t
16-200
\t
500W
\t
1000W
\t
10-150
\t
235W
\t
475W
\t
16-250
\t
600W
\t
1250W
\t
10-200
\t
300W
\t
600W
\t
16-300
\t
750W
\t
1500W
\t
10-300
\t
470W
\t
900W
\t
18-100
\t
250W
\t
550W
\t
12-60
\t
115W
\t
225W
\t
18-150
\t
400W
\t
850W
\t
12-100
\t
200W
\t
375W
\t
18-200
\t
550W
\t
1150W
\t
12-120
\t
225W
\t
450W
\t
18-300
\t
850W
\t
1500W
\t
12-150
\t
280W
\t
550W
\t
20-100
\t
300W
\t
650W
\t
12-200
\t
375W
\t
750W
\t
20-150
\t
450W
\t
950W
\t
12-300
\t
550W
\t
1000W
\t
20-300
\t
950W
\t
1800W

Notes:

1. The above list as normal item for your reference only
2. tube diamter: Φ3mm-Φ30mm
3. max wattage density: 25w/cm2
4.More details, welcome to email, let's disucuss together

Detail Images
\t\t\t\t\t\t\t\t\tRelated products \t\t\t\t\t\t\t

                    cartridge hater

              Flange cartridge heater

            Silicon Nitride ignitor

                  Immersion heater

                   Tubular heater

  Immerison heater with thermostat

Certifications
Packing & Delivery
\t
Packaging
\t
Size
\t
40 (L) * 28 (W) * 28 (D)
\t
Weight
\t
20KG of VINSON Harman Pellet Stove 336W / 240V 15 Fin igniter heater element
\t



Packaging Details
\t
The normal package is Carton(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
\t\t\t\t\t\t\t\t\tOur Factory \t\t\t\t\t\t\t

Yancheng Vinson Technology Co., Ltd was established in 2001 and has about 20 years' production history. We have been engaged in the development, design, production and sales in one of the sales of industrial technology company, according to the customer needs, provide tailored solution of design, committed to the electric heating and temperature measurement in the field of development.
"Quality is in my hand, Customer is in my heart" Quality is our culture, Our products have been exported to Europe, America, Asia, Mid East etc more than 200 countries. We are extensively used in electric heating and other industries. We hope our products and services can benefit your company, and our cooperation can be mutually beneficial win-win situation.

\t\t\t\t\t\t\t\t\tFAQ \t\t\t\t\t\t\t

1.Q:Are you a factory or trading company?
    A: Yes we are the factory and have 10 production lines for us.

2.Q:What's the shipping method?
   A: International express and sea transportation,Depend on customers.

3.Q:Can I use my own forwarder to transport the products for me?
   A:Yes, if you have your own forwarder in Shanghai, you can let your forwarder ship the products for you.

4.Q:What's the Payment method?
   A:T/T, 30% deposit before production, the balance before delivery.
      We sugguest you transfer the full price at one time. Cause there is bank process fee, it would be a lot of money if      you make twice transfer.

5.Q: What is our payment term?
   A:We can accept the payment by T/T,  Ali Online, Paypal,Credit card and W/U .

6.Q:Can we print our own brand?
   A: Yes, Of course.Will be our pleasure to be one your good OEM manufacturer in China to meet your OEM requirements.

7.Q:How to Place an order?
   A:Please kinldy send us your order by email , we will confirm the PI with you.

\t\t\t\t\t\t\t\t\tContact us \t\t\t\t\t\t\t
