Высокопрочная дверь с быстрым затвором грузовая душевая кабина вращающейся

The rails on both sides of the door frame are equipped with a sealing brush to prevent insects and dust, and to prevent wind and noise. Fast roll door performance is strong, no dust, efficient, stable, waterproof, easy to clean. The bottom end is equipped with an aggravating cloth, which can be closely combined with various uneven floors to achieve better sealing effect.

Adopt the filtering system of primary level and advanced level, Efficiency is above 99.99%,Equipped with large air volume and low noise fan to ensure the wind speed at the outlet is above 25m/s.

The cargo shower box adopts modular design scheme, It can be assembled and connected into air shower channels of different lengths and shapes according to actual needs.

The internal control system adopts single chip microcomputer control and PLC control curtain door to merge into oneThe LED screen visually displays the entire cleaning state, double-sided automatic induction interlocking, automatic induction blowing, and automatic opening and closing according to the process.

Door automatically roll up. Can do Super wide door. Maximum use of space, with high performance, high reliability, high stability, high precision positioning, etc..

1. Starting screen: the required operation can be carried out according to the prompt button on the screen. The air shower time is the air shower time displayed; If air shower is forced on the goods, after both front and back doors are closed, press the CLR key on the text to start air shower, and the air shower will automatically end at the set time, and the inner door will automatically open.

2, air shower time, both inside and outside the door shut time delay can be SET in the text, press on our (1), enter setting screen press the SET key on the operation panel, door of the delay time close to 0 and flashing, using the number keys on the panel type you want to SET the time, press the ENT key, time setting, close colleague who delay time to 0 and flashing, also through the numeric keys to SET the shutdown delay time, you need press ENT key SET is complete, the wind leaching time is SET in such a manner.

3, when the fast volume door fault, can be in the text on the fault query on the text to choose the fault of the door, if it is the outer door to press the key (1), the inner door press the key (2) to query, if the communication between the PLC fault, communication error indicator anti color.

4, external door fault inquiry screen: when photoelectric fault (generally not aligned, photoelectric green light is normal, otherwise abnormal), photoelectric indicator light anti-color. Other faults when the corresponding indicator inverted color.

5. Internal door fault inquiry screen: the fault display is the same as the external door.
