Буксируемый экскаватор-погрузчик с бензиновым двигателем KOHLER 9.5HP сертификат

Описание и отзывы

Трекер стоимости

Характеристики



Features:



1) 9hp self powered backhoe



2) matched any trailer



3) It is used for dicthing in farms and grazing lands, digging pool, cleaning waterways as

well as assistant excavating work in construction and building roads.



4) Hydraulic transmission is used. featured with compact structure. Flexibility, convenient operation and quick mounting and dismounting









Options for Additional Configuration:



1) 200mm, 300mm, 400mm, 500mm, 600mm wide extra buckets
2) 9HP Gasoline engine brand like Kohler, Honda, B&S etc.

3) Gasoline engine bigger power like 15HP.

4. Tyre can be changed as your request



MODEL	ATV-9
Power	9HP/15HP Gasoline engine
STRUCTURE WEIGHT	550kgs
MAX DIGGING DEEP	2400mm
MAX DIGGING RADIUS	2800mm
MAX DIGGING HEIGHT	2500mm
MAX UNLOADING HEIGHT	1200mm
STABILIZER WIDTH	1800mm
SWING ANGLE FOR BOOM	140 degree
BUCKET TURNNING ANGLE	160 degree
BUCKET CUBAGE	0.036m³
BUCKET WIDTH	Optional: 220mm/300mm/400mm/500mm,600mm
PUMP	DOUBLE SPEED GEAR PUMP
COUPLER SIZE	2" BALL FOR EASY TOWING
DIMENSIONS (L x W x H)	1800mmx1100mmx900mm
