ZRAY-D гравировальная пластиковая печатная машина 8
- Категория: Машины для ротационной глубокой печати >>>
- Поставщик: Ruian,Toyo,Imp,And,Exp,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 218544.64 $* | 229471.21 $* |
| Aug-19-2025 | 216707.17 $* | 227542.16 $* |
| Jul-19-2025 | 181814.88 $* | 190905.25 $* |
| Jun-19-2025 | 213034.88 $* | 223686.60 $* |
| May-19-2025 | 185487.29 $* | 194761.70 $* |
| Apr-19-2025 | 209361.78 $* | 219829.12 $* |
| Mar-19-2025 | 207525.61 $* | 217901.89 $* |
| Feb-19-2025 | 205688.29 $* | 215972.36 $* |
| Jan-19-2025 | 203852.76 $* | 214045.99 $* |
Характеристики
Ruian Toyo
Why Choose Us
Products Description
Type | ZRAY-81200D |
Max width | 1230mm |
Max.Printing Speed | 150m/min |
Max Mechanical Speed | 180m/min |
Max.Diameter Material Roll | Φ600mm |
Diameter of Roll Core | Φ76mm |
Diameter of Printing Cylinder | Φ100~Φ350mm |
Accuracy of Computer Regist | ±0.1mm |
Tension Control Range | 3~30kg/Full Width |
Total Power | 240kw |
Weight Mchine | 30000kg |
Overall Dimension | 16500×3200×2800mm |
Product Application:
This rotogravure printing machine is designed and developped by ourselves, high speed computer auto register gravure machine, it
is suitable for all kinds of plastic film, paper and other roll type material color printing.used in biscuit bag,industrail
bag,food package,water package or any other soft-package area. with reasonable design, beautiful surface, realiable quanlity, high
automatically, actually register, high yield, it is the high cost-effective printing device in china nowaday.
This rotogravure printing machine is designed and developped by ourselves, high speed computer auto register gravure machine, it
is suitable for all kinds of plastic film, paper and other roll type material color printing.used in biscuit bag,industrail
bag,food package,water package or any other soft-package area. with reasonable design, beautiful surface, realiable quanlity, high
automatically, actually register, high yield, it is the high cost-effective printing device in china nowaday.
Main Features:
1)Unwinding and rewinding high speed change material,no stop
2)Four float roll seven motor synchronous tension close loop control
3)Three-position pneumatic double-shaft blade, movement:6mm
4)Double leadscrew longitudinal auto color register structure
5)Outside separate type heating system
6)Shaftless type,embossing rubber roll inch up and down,and auto lock of cylinder
7)JAPAN Fujikura low friction cylinder control tension float roll
8)Japan yaskawa inverter and ABB motor
9)High static picture and precision overprint system(brand is optional)
1)Unwinding and rewinding high speed change material,no stop
2)Four float roll seven motor synchronous tension close loop control
3)Three-position pneumatic double-shaft blade, movement:6mm
4)Double leadscrew longitudinal auto color register structure
5)Outside separate type heating system
6)Shaftless type,embossing rubber roll inch up and down,and auto lock of cylinder
7)JAPAN Fujikura low friction cylinder control tension float roll
8)Japan yaskawa inverter and ABB motor
9)High static picture and precision overprint system(brand is optional)
More Products
Our Services
Export to Pakistan, Bangladesh, India, Mexico, Jordan, Egypt, Vietnam, Nigeria, Saudi Arabia etc countries
Verified by Alibaba ,No Any Risks Of Payment
100% payment protection
100% payment protection
Able to provide
Mechanical test report
Video factory inspection
Guarantee product quality and integrity
Mechanical test report
Video factory inspection
Guarantee product quality and integrity
About Us
Production Process
Packing&Transport
FAQ
1. your company is a manufacture or a trading company?
We are a manufacture. We also have a trading company to do export work.
2. What is the terms of payment you accept?
We can accept the T/T payment, we need 30% of total amount as deposit,pay the 70% balance before delivery, we can also accept the L/C,western union,paypal,private account,cash and others.
3. Where is your factory located ? How can I visit there?
Our factory located in ruian city, the nearest airport is WENZHOU airport, the nearest train staion is RUIAN station. If you need,
we can we pick you up from airport or train station.
4,What about the warranty?
All of our machines have 1 year warranty, if need we send engineer to install and test, buyer pay for the round air-tickets, food,hotel and transport, pay our engineer 100usd / day / person as salary.
In warranty period, if spare parts broken, we exchange for free. after the warranty period, we supply the machine’s full life service, buyer pay for the material cost of exchanging spare parts and repairing.
We are a manufacture. We also have a trading company to do export work.
2. What is the terms of payment you accept?
We can accept the T/T payment, we need 30% of total amount as deposit,pay the 70% balance before delivery, we can also accept the L/C,western union,paypal,private account,cash and others.
3. Where is your factory located ? How can I visit there?
Our factory located in ruian city, the nearest airport is WENZHOU airport, the nearest train staion is RUIAN station. If you need,
we can we pick you up from airport or train station.
4,What about the warranty?
All of our machines have 1 year warranty, if need we send engineer to install and test, buyer pay for the round air-tickets, food,hotel and transport, pay our engineer 100usd / day / person as salary.
In warranty period, if spare parts broken, we exchange for free. after the warranty period, we supply the machine’s full life service, buyer pay for the material cost of exchanging spare parts and repairing.
