Промышленный компьютер/ПК i3-7100U/i5-7200U/i7-7500U 6 * USB 6COM Max.16GB оперативная память 2 SATA3.0/1 MSATA3.0/Realtek 8111F 2*1000M

QM9600,QM9700 motherboard Spec.

Intel Processors

QM9600 motherboard supports 3855U,3955U,I3-6100U,I5-6200U,I7-6500U,etc.

QM9700 motherboard supports 3865U,3965U,I3-7100U,I5-7200U,I7-7500U,etc.

Form Factor(Size)

Mini-ITX,170*170*18mm(L*W*H)

Chip set

Integrating Intel Soc chip set in CPU.

Memory

2*SO-DDR3L 1600/1866 low voltage(1.35V) dual memories,supports Max.16GB RAM.

Display Interfaces

Integrating HD510/HD610 GPU;

Supporting Dynamic Memory Allocation(DVMT);

Supporting HD-MI,VGA,LVDS display interfaces;

Supporting three screens to display;

HD-MI display interfaces support 4K resolution display;

Supporting dual 8,24 bit LVDS.

Hard Disk interfaces

2*SATA3.0 , 1*MSATA3.0

Network Interface

1*Realtek8111F 1000M RJ45 LAN;

Supporting Wake On LAN(WOL);

Having 2*1000M LAN to choose.

Audio Interface

Integrating Realtek ALC662 HD digital audio decoder;

Supporting Line-Out,Mic-In interfaces,and have front pin on board;

Supporting 3W/5W power amplifier speaker.

I/O Expansion

4*USB3.0 , 6*USB2.0 , 6*RS232 COM , 1*RS485;

Supporting to take the electric 5V/12V from COM interface.

Expansion Bus

2*Mini PCI-Express slots,supports optional WIFI/3G/GPS/MSATA.

System Monitor

/ Watch dog

Supporting CPU temperature monitor, fan speed,system temperature.

Operating Environment

Working temperature :-10~60℃

Relative humidity:5%~95%,non-condensation.

Power Supply

DC 12V or 19V power adapter.

BIOS

AMI BIOS,support read only;Power switch,timer switch,remote switch equipment Intelligent identification.

Operating System

Win 7(64bit,32bit),Win 8,Win10,Linux.

Fitted Mini PC Chassis

HD4000,HD4001,IPC6000
