Новые женские ботинки размер мобильный бетонный транспортное средство Самостоятельная погрузка бетономешалки кормления Миксер с


Поделиться:


Цена:30 000,00 $ - 30 500,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-19-2025 35700.16 $* 37485.20 $*
Aug-19-2025 35400.43 $* 37170.29 $*
Jul-19-2025 29700.4 $* 31185.17 $*
Jun-19-2025 34800.3 $* 36540.31 $*
May-19-2025 30300.93 $* 31815.42 $*
Apr-19-2025 34200.59 $* 35910.11 $*
Mar-19-2025 33900.35 $* 35595.8 $*
Feb-19-2025 33600.47 $* 35280.18 $*
Jan-19-2025 33300.9 $* 34965.84 $*

Характеристики


Product Description

Product Application

new size mobile concrete batching vehicle self loading concrete feeding mixer with truck


1.Stirring device is mainly composed of mixing drum and auxiliary support components.< Mixing drum of concrete loaded containers, rotates the concrete along the blade spiral direction, constantly in the process of ascension and turning by mixing and stirring. In the process of feeding and transport, mixing barrel forward, concrete, moving along the blade into the discharge, the mixing tube inversion, the concrete to discharge along the blade.
2.Blade is the main components in the mixing plant, serious wear and tear or damage can lead to concrete mixing unevenly. In addition, the Angle of the blade if the design is not reasonable, still can make concrete segregation.
3.Cleaning system is the main purpose of cleaning the mixing barrel, is also sometimes used to transport on the way to dry mixing drum. Cleaning system and cooling effect to the hydraulic system. Totally enclosed device adopts rotary sealing technology, sealed the mixers in and out of the mouth, to solve the traditional mixing heavy evaporation, stratification of mortar,concrete material spilled, the series of problems such as driving safety.

mixing drum
Drum capacity:6.5m³
Real capacity : 4.0M3
 14m3 concrete output/h,up to 4 batches per hour
mixing speed: 3 gears both positive & inversion turns;
maxing slewing angle of the drum: 270 degree.
engine paramters
Yuchai 4108 Turbo , rated power/turns: 95kw (129HP)/ 2400rpm.
drive system
hydraulic component( variable stroke pump) : Danvers
two grades gear transmission : road/off road, 4wheel drive,two wheel steering
speed
low gear speed: 0-9.5km/h, high gear speed : 0-28km/h
cabin
front cabin with rops &fops design
Hydraulic sytem
2 variable stroke pumps provide power separately to car drive and mixer.

2 constant rate pumps provide power to drum slewing , brake, water.

cooling: water/air
joystick
all working operation designed in one joystick
bucket
capacity: 0.6m3 hydraulic controlled door
chute
adjustable hydraulic controlled vertical 15 degree movement, horizontal free movement
water sytem
water pump with high pressure washing gun
climbing angle
30 degree with full load
brake
wet brake, parking brake with gear box
tires
off-road engineering tire 16/70-20 PR16
steering
Back axle steering, all hydraulic

inner steering radius: 1988mm/4130mm

outer steering radius:3767 mm/6030mm
electric system
battery :2X12V    120Ah, provide lighting and ignition
fuel tank
110L
hydraulic oil tank
80L
carframe
all steel welding
weight
off load:8t, full load :18t
weighing system
equipped with high precision concrete weighing system & micro printer for detailed data of weight price, date etc.
Discharge
60°,discharge concrete
Dimensions(LxWxH)
6100*2300*2900
Detailed Images





weighing system







Reversing and side car images







air conditioning system







Unloading trough


Certifications
Packing & Delivery
Packaging



Packaging Details




The normal packing is fixed with Mutuojia cable.
Packaging



Packaging Details



The normal packing is fixed with Mutuojia cable.
