Шаблон для швейной машины с логотипом
- Категория: Магазин одежды машины >>>
- Поставщик: Dongguan,Xingchi,Sewing,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 3035.81 $* | 3187.84 $* |
| Aug-20-2025 | 3009.64 $* | 3159.58 $* |
| Jul-20-2025 | 2525.85 $* | 2651.40 $* |
| Jun-20-2025 | 2958.41 $* | 3106.34 $* |
| May-20-2025 | 2576.69 $* | 2705.9 $* |
| Apr-20-2025 | 2907.16 $* | 3052.71 $* |
| Mar-20-2025 | 2882.59 $* | 3026.66 $* |
| Feb-20-2025 | 2856.13 $* | 2999.41 $* |
| Jan-20-2025 | 2831.92 $* | 2973.78 $* |
Характеристики
Product Description
Product application
Pattern sewing machine XC-2010R with extra device:
1. Reversal deivce: Prevent the material moving when stitching
2. Side slide device:Hold the material when stitching
XC-2010R computer pattern sewing machine is suitable for medium/ heavy duty sewing such as trademark, logo
Item Name | XC-2010R(with extra device) | XC-2516R | XC-3020R |
Sewing area | 200*100mm | 250*160mm | 300*200MM |
Needle | DP*17 #22(#18-25#) | Same | Same |
Max speed | 2500rpm | Same | Same |
max stitching length | 0.1-12.7mm | Same | Same |
Press foot Alternating movement | 4-10mm | Same | Same |
Hook | Rotary hook | Same | Same |
Machine head type | Misubishi type | Same | Same |
Press foot adjustable height | 20mm | Same | Same |
Clamp adjustable height | 32mm | Same | Same |
Main motor | Direct drive motor 750w | Same | Same |
Transmission motor(X,Y axis) | Stepper motor 550W | Same | Same |
Voltage | 220V | Same | same |
Volume | 1.3 | 1.3 | 1.4 |
Gross weight | 150KG | 160kg | 170KG |
Reversal device:- Prevent material move when stitching .
Application: to sew small trademarks and logos automatically and quickly( X,Y axis size of XC-2010 200*100mm)
As above pictures showing how it works step by step:
1. Pressing the material under the pattern panel steadily, and start to sew within the U shape area;
2. Continue to sew till the edge of U shape presser foot;
3. The U shape presser foot turns over 180° to the other side, allows the needle to finish sewing the full pattern;
4. After presser foot lifting, the U shape presser foot also resets and waits for the next round.
Side sliding Device
Application: to sew tiny trademarks and logos automatically and quickly( X,Y axis size of XC-3020R:300*200mm)
As above pictures showing how it works step by step:
1. Placing the logos into the pattern sewing hole;
2. Make sure the logos placing in the right position;
3. The side-sliding presser foot moves in, presses against the logo then starts sewing according to the pattern design;
4. When sewing stitch goes near the presser feet, the press feet resets, moves away to make room for full lockstitch.
Design Features
1.X, Y axis transmission sensor
Can quickly detect the machine arm transmission range, to control the raw material pattern within the sewing range.
2. Effective oil supply
Supply oil slowly when working, prevent high wastage during production process; indicator shows the oiling situation for daily maintenance.
3.Transmission gear and rack
Auto transmission system set workers free from moving the material to sew, just need to handle the material into the pattern panel, get the job done by pressing one button.
4.Big rotary hook & auto cutting
Twice big hook and shuttle means half time in pause and changing bottom thread, improve the production efficiency. As per pattern design, when rotary knife move to the fixed knife, the thread will be cut automatically.
5.Stepper motor for X, Y axis transmission
Unlike sewing head using direct drive servo motor, the X,Y axis transmission uses stepper motor, avoid any interruption of voltage or current change, stop moving exactly when needed.
6.Full touch screen and simple interface
Six operating languages: Chinese, English, Japanese, Korean, Burmese, Turkish.
Colour graphics display, easy to operate and edit design, we have videos to teach people how to sew.
Production Process
Production takes time and effort.
From pieces of raw material, we clean, assemble, grind, etc., step by step and finally the our technology become part of the machine.
Before the machine serves the users, so many works had been done by our engineers, workers and QCs.
With such hard work, quality of our machines is filled with confidence and pride.
Our Company
Our Vision: Focus on quality & technology
* 19 years' effort on improving quality and technology.
* Large amount of R&D investment in sewing machine industry.
* Great attention on feedback concerning quality and technology.
* Engineering and service team work together to handle technology issues.
Xingchi Provide sewing equipments including whole set or spare parts of sewing machine:
* computer sewing machine series
* 341cylinder bed series
* debburring machine for box & handbag
* cylinder bed series
* computer automation series
* post bed series
* lockstitch zigzag sewing machine series
* special function series
* double needles sewing machine series
* flat bed series
* lockstitch sewing machine with top and bottom
* post bed bottom feed sewing machine
* post bed series
* overlock sewing machine series
* leather skiving machine
* automatic plastic folding machine series
Our Service
Service
Pre-Sale Service:
1.We can give you the professional suggestion of the machine based on your products.
2. Give you the instructions of the machine.
3. Teach you how to make the pattern. (There is a video for this and we have instuctions)
4.For the mould we can teach you how to make the mould of the machine.
5.Teach you how to make the pattern in the computer and convert the file to the machine. Which very easy.
6. If you buy the machine, together with the machine there is a free mould and some spare parts together with the machine.
After Sales Service:
We have professional afterservice department.
1.We can teach you how to solve the problem by yourself via video call or send you the video, if there is any problems.
2.If any wearling parts broken, we have the spare parts, we can provide spare parts for you.
3.If the problem can't solved via video and with the warranty, you can delivery the parts to our company, we help to fix it for free within the warranty.
Packing & Delivery
Xingchi guarantees to pack and deliver as per customers' request.
For head only: packed with carton, protected with foam, and certain cartons in a wooden box.
For whole set: head and accessories fixed with polybag after assembling and testing, then packed in wooden case.
Packaging | ||
Size | 1250 (W) * 750 (D) * 1340 (H) | |
Weight | 180kg | |
Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. | |
Related Products
XC-3020G Pattern Sewing Machine G type
93.8% Response Rate
XC-3020R Pattern Sewing Machine
91.8% Response Rate
XC-6040RPattern Sewing Machine
95.8% Response Rate
FAQ
1. how can we guarantee quality?
Always a pre-production sample before mass production; all goods with Inspection before shipment;
2.what can you buy from us?
Sewing Machine and other related machines we can provide full production line machines for handbag, shoes, luggage, backpack, car seat, glove and other leather goods
3. why should you buy from us not from other suppliers?
1.We have more than 20 years of technical team
Always a pre-production sample before mass production; all goods with Inspection before shipment;
2.what can you buy from us?
Sewing Machine and other related machines we can provide full production line machines for handbag, shoes, luggage, backpack, car seat, glove and other leather goods
3. why should you buy from us not from other suppliers?
1.We have more than 20 years of technical team
2.We are the real factory.Standard assembly line
3.We have our own patent products can do OEM , ODM
4.We are familiar with the use of the sewing machine of handbags, luggage, leather goods, etc.
4. what services can we provide?
Accepted Delivery Terms: FOB,CIF, EXW ETC；
Accepted Payment Currency:USD,RMB; 30% deposit via T/T, 70% balance before shipping
Accepted Payment Type: T/T;
Language Spoken:English,Chinese
4.We are familiar with the use of the sewing machine of handbags, luggage, leather goods, etc.
4. what services can we provide?
Accepted Delivery Terms: FOB,CIF, EXW ETC；
Accepted Payment Currency:USD,RMB; 30% deposit via T/T, 70% balance before shipping
Accepted Payment Type: T/T;
Language Spoken:English,Chinese
5.what's the MOQ?
No MOQ, One set is ok.
No MOQ, One set is ok.
6.what's the Warranty?
Answer: One year warranty
7.What's the Cargo ready date?
Answer: For sample or small qty, the machine can be ready about 5-10days after payment received. For mass production, will based on your qty and request.
Answer: One year warranty
7.What's the Cargo ready date?
Answer: For sample or small qty, the machine can be ready about 5-10days after payment received. For mass production, will based on your qty and request.
