Лучший пропеллер 7GJ серии 6HP-160HP из нержавеющей стали с длинным валом для

Technical specification parameter list

 Item

Model

7GJ32

7GJ36

7GJ60

7GJ80

7GJ120

1

Speed (km/h)

No-load speed(kn/h)

≥16

≥10.5

≥10.5

≥13

≥13

Rated heavy load speed(kn/h)

≥14

≥10

≥10

≥12

≥12

2

Maximum column pull ahead (kg/force)

≥300

≥250

≥390

≥450

≥450

3

Overall dimensions L*W*H(mm)

930*590*1700

1800*600*250

1800*500*250

1800*500*250

1900*550*280

4

Hung-machine net weight(Kg)

130

167

189

195

250

5

 Auxiliary power

CF40M

 Rated power(KW/rpm)

32

36

60

80

120

Rated speed(r/min)

2200

2000

2000

2000

2200

6

 Load tonnage of matching ships(t)

20~25

7

The propeller

 Diameter(mm)

530

580

650

650

700

 Pitch(mm)

360

380

420

420

450

 Speed(r/min)

1200

1000

1000

1000

1000

 Rotation direction

Right

Right

Right

Right

Right

 Blade number

3

3

3

3

3
