Характеристики
Products Description
Features
Bag filters are mainly used to filter impurities in water, beverages, and chemical liquids. The filter bags are available in #1, #2, #3, #4, etc., and a stainless steel filter basket is required as a support. The filter has a large filtering area, high filtration efficiency, convenient operation and low maintenance cost. The height of the filter is adjustable for different applications.
Typical Application
● Food, beverage, and alcohol factories, meeting the sanitary requirement
● Filtration of petrochemical and chemical products
● Filtration of liquids in printing, furniture, etc.
Typical Application
● Food, beverage, and alcohol factories, meeting the sanitary requirement
● Filtration of petrochemical and chemical products
● Filtration of liquids in printing, furniture, etc.
Product Parameters
Working Principle
The ordinary liquid filter bag is made of PE (polyester) fiber, PP (polypropylene) fiber cloth, or MO (monofilament) mesh. PE and PP are deep three-dimensional filter materials. 100% pure fiber is processed by needle punching to form a three-dimensional, high-floating and tortuous filter layer. The 100% pure fiber is needle-punched into a three-dimensional, highly fluffy and tortuous filter layer. It is characterized by loose fibrous structure, which can increase the capacity of impurities. This filter is a double-cut mode that effectively removes solid and soft particles, allowing larger particles to be trapped on the fiber surface while fine particles are trapped in the depth of the filter. It ensures that it will not break due to increased pressure during use and has high filtration efficiency. In addition, the outer surface of the machine is high-temperature heat treatment, that is, instant sintering technology (calendering treatment), which can effectively prevent the fibers from being lost by high-speed impact of liquid during filtration. Thereby, both the contamination of the filtrate due to fiber detachment and the clogging of the filter pore caused by the conventional rolling treatment could be avoided, and the life of the filter bag is increased. In addition, this pressure difference is small, that does not affect the flow rate, and its accuracy is 1-200 microns.
MO is made of non-deformable nylon spinning, woven into a net according to the specified specifications, and becomes a single wire after heat setting. It is characterized by high strength and does not deform due to changes in pressure. The monofilament woven surface is smooth, easy to clean, and can be used repeatedly. It is also suitable for filtering some liquids with high impurity content, which can reduce the filtration cost, and its precision is 20 ~ 550 mesh (25 ~ 840μm).
Filter bag fixing ring material: stainless steel ring, galvanized steel ring, polyester / polypropylene plastic ringMaterial: Polyester (PE), Polypropylene (PP).
L = five-line seam - ring material (common galvanized steel, stainless steel)
A= bag 1, B= bag 2, C=bag 3, D= bag 3
Filtration area: bag 1 = 0.25, bag 2 = 0.5, bag 3 = 0.8, bag 3 = 0.15
Dimensional tolerance mm: ≥0.3-0.8 ≥0.3-0.8 ≥0.3-0.8 ≥0.3-0.8
Filtration fineness (μm): 1, 3, 5, 10, 15, 20, 25, 50, 75, 100, 150, 200
Maximum Operating Pressure Difference (MPa): 0.4, 0.3, 0.2
Maximum Operating Temperature (°C): Polyester (PE): 130 (instantaneous 180); Polypropylene (PO): 90 (instantaneous 110)
MO is made of non-deformable nylon spinning, woven into a net according to the specified specifications, and becomes a single wire after heat setting. It is characterized by high strength and does not deform due to changes in pressure. The monofilament woven surface is smooth, easy to clean, and can be used repeatedly. It is also suitable for filtering some liquids with high impurity content, which can reduce the filtration cost, and its precision is 20 ~ 550 mesh (25 ~ 840μm).
Filter bag fixing ring material: stainless steel ring, galvanized steel ring, polyester / polypropylene plastic ringMaterial: Polyester (PE), Polypropylene (PP).
L = five-line seam - ring material (common galvanized steel, stainless steel)
A= bag 1, B= bag 2, C=bag 3, D= bag 3
Filtration area: bag 1 = 0.25, bag 2 = 0.5, bag 3 = 0.8, bag 3 = 0.15
Dimensional tolerance mm: ≥0.3-0.8 ≥0.3-0.8 ≥0.3-0.8 ≥0.3-0.8
Filtration fineness (μm): 1, 3, 5, 10, 15, 20, 25, 50, 75, 100, 150, 200
Maximum Operating Pressure Difference (MPa): 0.4, 0.3, 0.2
Maximum Operating Temperature (°C): Polyester (PE): 130 (instantaneous 180); Polypropylene (PO): 90 (instantaneous 110)
Product details
Product Paramenters
Advantages
Certification | 25 National Patents, Audited by SGS/TUV/CE/ISO9001 |
Quality Guarantee | Complaint rate as low as 5‰ for 15 years. If you decide to purchase from us, any malfunction happened, once you enquiry us, we will reply you solution within 48 hours except the special reasons |
Short Lead Time | Lead time is flexible. Short turnaround of replacement parts made by substantial storage, Normally we are 20% faster than others. If you have urgent orders, pls feel free to contact us. We will get the job done with 100% satisfaction. |
24/7 Available | All your inquiry will be responded within 1 hour. All your quotation will be satisfied within 12 hours. |
Why choose us？ | •100% manufacturer • Rich production experience •Strict Quality Control System •Flexible MOQ •Punctual delivery •Excellent and Experienced Team |
Company Profile
Wenzhou Qiangzhong Machinery Technology Co., Ltd. is a professional manufacturer of processing machines, located in Wenzhou City, China, near Longwan International Airport. Our main products include the high shear mixer, mixing tank, colloid mill, sanitary pump, sanitary filter, sanitary pipe, and valve. They are widely used in industries such as brewery, dairy product, beverage, chemicals, cosmetics, pharmaceuticals, and biopharmaceuticals.
We offer complete sets of service from research and development, production, sales, after -sales to maintenance, in accord with GMP, QS, and HACCP. As a pioneer and innovator, Obtain 25 National Patents, Audited by SGS / TUV / CE / ISO9001.
Thanks to advanced technologies and production equipment, strict meeting industry standards, our quality is well-developed continuously. So far, our products have been sold not only all around China but also globally, such as Europe, America, Australia, Southeast Asia, Middle East, etc.
