Автоклав вулканизатор резиновый продукт Вулканизация Резина автоклав паровой нагрев натуральный каучук под заказ ASME CE ISO 15 3 куб.

Product Description

Heating Type: Hot air heating

Opening door type: Manual quick opening, single man can easily complete all the steps. This design is the most advanced way and idea of opening the door. Open and close the door normally when it is power failure.

Sealing Method:The door uses inflatable silicone sealing ring, which is simple and convenient to maintain and the sealing effect is obviously better than other methods with more than 2 years of service life.

Safety chain type: 3 sets of safety interlock devices are designed at the tank door. It solves the safety problems caused by mistaken operation completely.

(2)\tPressure automatic safety chain (2) Manual safety chain (3) Sealing ring safety chain

Control Type: PLC Computer Full-automatic Control, Computer Semi-automatic Control and Manual Control

Insulation Type: It uses double layer external insulation, saving thirty percent of energy consumption than ordinary insulation.

Loading mode: There are two 36# steel rail with the national standard in the tank. A filtering net is covered in the discharge hole which is easy to clean the sundries without clogging the outlet.

Product Application

Widely used in vulcanization of rubber products, SBR thermoplastic as well as the carbonization and degreasing of bamboo, such as, rubber, cable, printing and dyeing, chemical, building materials and other industries. Mainly used in rubber products, rubber hose, rubber roller etc.

Used in tire, rubber sleeve cable, rubber shoes, rubber hose, rubber roller, rubber belt, belt, conveyor belt, rubber ball, rubber lining, rubber cloth, rubber head, gloves, red flag, etc.

Wood drying, wood preservative, wood fire prevention, wood impregnation, wood color, wood cooking, bamboo carbonization, wood modification, wood optimization, wood fire retardant

Also used for Yarn thread, mane, socks heat setting, high pressure modification and degreasing of horn and bone, feather hydrolysis, oxidation treatment of aluminum products, steaming and cooking of carbon materials, asbestos friction materials, gypsum and its products.

Main Features

Automatic control: From heating, preserving heat to vulcanizing and so on all the processes is completed by control system.

Safety: The heating tube uses nickel chromium material of heating wire, which is welded with external line terminal in case of fire.

Uniform temperature and pressure: High temperature air cycles in the tank through the special air duct plate, spreading the heat from front to back, to ensure uniform temperature in the tank without dead ends. This solves the problem of product quality.

Simple and convenient operation: Use of advanced and convenient design concept and manufacturing process, the operators can learn all the operating process in 15 minutes.

Temperature, pressure and curing time is controlled automatically. The steam inlet is controlled by angle seat valve and is arranged at the bottom of the tank. Steam diffusion tube is arranged at the bottom inside the tank vertically, of which the steam mouth (4mm, 5mm) is arranged densely according to certain rules and angles to ensure the temperature spread around evenly. After setting working procedures, it can carry out air intake, exhaust, temperature rising, heat preservation and vulcanization automatically. When it ends, it will shut down and send out the sound and the light to alarm.

Machine Parts

Name: RUBBER AUTOCLAVE DOOR

Brand: MOSEN

Original:  CHINA

Rubber autoclave dish is main part of rubber autoclave door, it  made of Q345R, this rubber autoclave dish is specially designed for rubber vulcanization and for rubber autoclave good sealing with good performance.

Main Features

Name: Bliwing Cylinder
Brand: FESTO
Original: Germany
Carbon steel flange connects the rubber autoclave dish to rubber autoclave cylinder to complete the whole rubber autoclave. We use domestic famous brand.

Machine Parts

Name: Flange
Brand: MSOEN
Original: China

Q345R flange connects the autaoclave dish to rubber autoclave cylinder to complete the whole rubber curing autoclave. We use domestic famous brand.

Main Features

Name:Pneumatic ball valve
Brand: MOSEN
Original: CHINA
Adjusting the amount of steam entering the rubber vulcanization autoclave is relatively accurate

We will deliver your goods by LCL/20'FCL/40'FCL depending on your order.

Before delivery, our professional technician will do trial run for each product to check until everything is functional, you also can come to our factory and test our machine together with us.

When loading, our workers will fix the retorts tightly with wire rope so that the retorts can't move in the container.
