Экскаваторная сваевая головка резак дробилка для

Your problems

How can we solve it?

Dangerous

1. Contact-free operation is enabled.
2. And it imposes no impact force on the parent body of the pile and no influence on the bearing capacity of the pile.

Slowly

1.Replaceable and changeable module combination makes its applicable for piles with various diameters.
2.The modules can be assembled and disassembled easily and conveniently.

Noisy

Its full hydraulic drive causes little noises during operation and no influence on the surrounding environments

Expensive  salary

1.Fewer operating workers are required to save cost for labor and machines maintenance during construction.
2.Suitable for different kinds of carrier.
3.Module generalization is realized with our SP380 and SP400-Bsquare pile machine. It can be used for both circular piles and  square piles by changing the module combination

Nondurable

1. It is made of military material by first-class suppliers with reliable quality, extending its service life.
2.The mainboard used Q345B and the chisel used the 42Crmo.
3.12 month after-sales service.
4.Provide 50 spring pins for free.
5.Professional small tools for free.

(1)

The mechanical stress is put pressure on the structural parts not on the connection when it worked and the oil cylinder which is specially-made by Sany used the double oil seal.

(2)

There are 7 kinds of pin axle holes to match different shaft. To prevent the form of pile breaker from changing when it works.

(3)

The shackle loading weight is 3 tons .Meet the national standards.

(4)

The chain hoist is adjustable and the loading weight is 4 tons.

Product option

            SP606/SP380          SP400-A              SP400-B                  SP500

Model

SP606

SP380

SP400-A

SP400-B

SP500

Range of pile diametre(mm)

1700-1850

950-1050

300-400mm

300-400mm

400-500mm

Maximum drill rod pressure

690KN

320KN

320KN

320KN

320KN

Maximum stroke

of hydraulic cylinder

180mm

150mm

150mm

150mm

150mm

Maximum pressure

of hydraulic cylinder

34.3Mpa

34.3Mpa

34.3Mpa

34.3Mpa

34.3Mpa

Maximum flow single cylinder

25L/min

25L/mim

25L/mim

25L/mim

25L/mim

Cut the number of pile/8h

40-100

60

160

160

120

Height for cut pile each time

≤300mm

≤300mm

≤300mm

≤300mm

≤300mm

Supporting the digging machine tonnage(excavator)

≥35T

≥20T

≥7T

≥8T

≥15T

One-piece module weight

280kg

110kg

/

110kg

200kg

One-piece module size

908*680*380

604*594*286

/

604*594*286

595*980*275

Work status dimensions

3200*3000

2268*2500

1440*1440*1500

1600*1600*2000

1710*1710*2500

Total pile breaker weight

3.7T

1.5t

600KG

650KG

960KG
