Optical Enlargement

3.5X-90X

Eyepiece

High eyespots wide-field eyepiece WF10X/20 mm

Objective lens

0.7X-4.5X

Viewing Head

Trinocular stereomicroscope view head  inclined at 45°.

The pupil distance adjusting range 54mm-76mm

Working Distance

30mm-165mm

Auxiliary lens

0.5X/165mm,2X/30mm

Focusing bracket

Focusing handwheel tightness is adjustable, lifting range 50 mm

Dual arm bracket

Lifting range: 275mm, base column 210*260*51mm,lens diameter 32mm,lens aperture 76mm,vertical height 380mm, horizontal movement 235mm

LED light source

LED Qty 144,Internal diameter size 64mm,Diameter size 94mm,Input voltage AC90—240V,Maximum output power 4.5W,Voltage 12V0.5A

Camera eyepiece interface

Dedicated interface 1XCTV ,0.5X CTV

Output Interface

HDMI/USB

Sensor

sensor 1/2.3 inch

Image resolution

2592x1944 (for TF Card), 1920x1080(for TF Card),

Video recorder

1920*1080 @ 30fps

Pixel

14 megapixel

Pixel Size

1.43µm × 1.43µm

Frame rate

30fps

Digital magnification

5 times digital zoom

Brightness control

Auto/manual

White Balance

manual operation,automatic

Color

R/G/B adjustable

Image freezing

Support

OSD

Support

Cross cursor

Support multi-color, size adjustable

Transverse and vertical line

Support multi-color, 4 pcs of transverse lines/vertical lines, movable

TF card interface

Maximum support 32G

Camera interface

C

USB interface

Usb2.0

Power supply

DC-12V/1A
