ASME DOT ADR CSC CE одобренный 20-футовый газовый контейнер для сжиженного


Поделиться:


Цена:21 500,00 $ - 22 000,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-19-2025 25585.22 $* 26864.46 $*
Aug-19-2025 25370.72 $* 26639.64 $*
Jul-19-2025 21285.58 $* 22349.22 $*
Jun-19-2025 24940.63 $* 26187.7 $*
May-19-2025 21715.20 $* 22801.64 $*
Apr-19-2025 24510.62 $* 25736.52 $*
Mar-19-2025 24295.36 $* 25510.15 $*
Feb-19-2025 24080.53 $* 25284.39 $*
Jan-19-2025 23865.59 $* 25058.6 $*

Характеристики



Product Description











































































20 FEET LPG Tank Container



Design Code






ASME Code



Capacity






24,700L



Liquid






LPG



Frame Dimension(L*W*H)






6058*2438*2591mm



Tare Weight






6500kg



Max. Gross Weight






35000kg



Specified Design Pressure






1.8MPa



Internal MAWP



1.8MPa at 55



External MAWP



0.1MPa at 55



Design Temperature



55



MDMT



-40at 1.8MPa



Hydrotest Pressure






2.58MPa



Leakage Test Pressure






1.64MPa



Shell Material






SA-612M Normalized



Heads Material






SA-612M Normalized


















U2 Stamp






YES



















































































40 FEET LPG Tank Container



Design Code






ASME, IMDG, ADR, CSC, ISO



Capacity






51700L



Liquid






LPG



Frame Dimension(L*W*H)






12192*2438*2591mm



Tare Weight






11900kg



Max. Gross Weight






36000kg



Specified Design Pressure






1.8MPa



Internal MAWP



1.8MPa at 55



External MAWP



0.1MPa at 55



Design Temperature



55



MDMT



-40at 1.8MPa



Hydrotest Pressure






2.58MPa



Leakage Test Pressure






1.64MPa



Shell Material






SA-612M Normalized



Heads Material






SA-612M Normalized



U2 Stamp/U2






YES










Packaging & Shipping









Our Services


 The containers specified herein are manufactured under sufficient quality control, which will be approved by one of following authorized agency.





ASME, IMDG, ADR, CSC, ISO








Company Information




CIMIC Containers h longest history. Covering the manufacture of dry cargo container, refrigerated container and special container as well as thebusinesses of modular buildings and floor. Its annual production capacity of dry cargocontainer exceeds 2.4 million TEUs and the annual production capacity of refrigerated
container surpasses 0.19 million TEUs with products being widely used in North America, Europe, Asia and other world major logistics systems.


NEW 1.png







FAQ




1.  Standard and certificate:


ASME, IMDG, ADR, CSC, ISO,BV





2.  Productivity


100units per day


3.  Logo


Design and painting as your request


4.Payment


50% deposit , 50% before shipment


5. Guarantee


Five (5) years and be based on standard “RE 3” of the “European degree of rusting standards”. Normal wear/tear, or corrosion caused by fish oil, animal and vegetable oils, strong solvents, impact and accident is excluded.The warranty shall be applied faults or failures affecting more than 10% of the painted surface.


Decal guarantee   Seven (7) years.





6. Contact information


Email : artest_zhang2004 (@)aliyun.com or 313365674 (@)qq.com


Mobile phone: 008613920482102


Whatsapp: 008613920482102


Skype: 008613920482102
