Products Description
Overview:
Android 7.1 Industrial Control ARM mainboard from sunchip
Features:
Multiple interactive mode interfaces: infrared remote control, USB mouse.
A variety of network interfaces: Ethernet, 4G, wireless Wifi, Bluetooth.
Multi-channel USB interface, serial output.
Support 4K video playback.
Strong anti-electromagnetic interference and electromagnetic compatibility.
Product Parameters
CPU | Rockchip RK3328 quad core Cortex-A53 quad core GPU Mali-450MP2 |
Main frequency | 1.5GHZ |
Deposit | LPDDR3 1G/2G |
Built-in storage capacity | EMMC 8GB/16G/32G/64G optional (labeled8GB） |
Network | With RJ45 interface, support 10/100/1000 Ethernet |
Support 4G PCIE interface | |
With Wifi & BT module, support Wi-Fi 802.11b / g / n protocol. Support BT4.0 | |
Real Time Clock | Built-in real-time clock powered battery |
Interface device | Support USB camera |
6 USB HOST，1 USB 3.0 | |
SD card, maximum support 64GB | |
Class D amplifier: 5W*2 8 ohms, support microphone | |
Audio | MP3, AAC, WMA, FLAC, OGG, Dolby Digital, Dolby Digital Plus |
Video | Supports 1080P@60FPS decoding of video formats such as MPEG1, MPEG2, MPEG4, VP9, VP8, MVC, etc., and supports 4K@60FPS decoding of H.264 and H.265 video formats. |
Picture | Support JPG, BMP, PNG and other image formats to browse and support rotation / image zoom function |
Power Adapter | Input：AC100-240V.50-60HZ， Output： DC12V 3A |
Packing & Delivery
1.Packing: carton box or wood case
2.Payment methods: accept T/T,Western Union,Paypal and Cash.
3.RMA Policy: customer bear all the freight and duty charge to factory,and the factory afford return freight charge.
4.Warranty: 12 months warranty. Paid maintenance over 12 months.
5.Remark: ROHS, CE & FCC certificates in e-file format are available.
6.MOQ: 1pc, sample order are welcome for your evaluation.
2.Payment methods: accept T/T,Western Union,Paypal and Cash.
3.RMA Policy: customer bear all the freight and duty charge to factory,and the factory afford return freight charge.
4.Warranty: 12 months warranty. Paid maintenance over 12 months.
5.Remark: ROHS, CE & FCC certificates in e-file format are available.
6.MOQ: 1pc, sample order are welcome for your evaluation.
